5.0l flex fuel, charging circuit for Ford Pickup F150 (1996-2012)

3.5L AS RC BATTERY BATTERY CURRENT SENSOR (RIGHT SIDE OF ENGINE COMPT) BATTERY JUNCTION BOX (BJB) (FRONT OF ENGINE COMPT) BCS BLK/VIO WIRE BLU/ORG WIRE BLU/WHT WIRE BODY CONTROL MODULE (BCM) (RIGHT KICK PANEL) COMPUTER DATA LINES COMPUTER DATA LINES SYSTEM ENGINE CONTROLS FUSE GENCOM GENERATOR B+ GENERATOR CURRENT SENSOR (RIGHT FRONT CORNER OF ENGINE COMPT) GENMON GRY/BRN WIRE GRY/RED WIRE HIGH CURRENT BATTERY JUNCTION BOX (BJB) (RIGHT FRONT CORNER OF ENGINE COMPT) HS CAN - (3.7L) (5.0L) HS CAN+ INSTRUMENT PANEL CLUSTER (IPC) MEGA FUSE NCA WIRE POWERTRAIN CONTROL MODULE (PCM) (RIGHT REAR OF ENGINE COMPT) RED WIRE SIGRTN STARTER MOTOR SYSTEM VIO WIRE VIO/GRN WIRE VREF WHT WIRE WHT/BLU WIRE YEL/GRN WIRE YEL/VIO WIRE
