Wiring diagram engine performance 5.4ls, with 4r70w transmission (4 of 4) for Ford Pickup F150 (1996-2012)

A/C CLUTCH RELAY BATTERY JUNCTION BOX (ON LEFT SIDE OF ENGINE COMPARTMENT) BLK WIRE BLK/PNK WIRE BLK/WHT WIRE BRN/LT BLU WIRE BRN/LT GRN WIRE BRN/WHT WIRE BRN/YEL WIRE CAMSHAFT POSITION (CMP) SENSOR (ON FRONT OF ENGINE) CENTRAL JUNCTION BOX (UNDER LEFT SIDE OF DASH) CHECK FUEL CAP IND COOLING FAN SYSTEM DIGITAL TRANSMISSION RANGE SENSOR (DTR SENSOR) (LEFT SIDE OF TRANSMISSION) DK BLU/YEL WIRE DK GRN WIRE DK GRN/VIO WIRE DPFE SENS CYL HEAD TEMP CANISTER VENT VSS (+) WOT RELAY FROM DTR SENSOR (DIAGRAM 1 OF 4) FUEL TANK PRESS FUSE 15 FUSE 2 FUSE 20 GRY/BLK WIRE GRY/LT BLU WIRE GRY/RED WIRE GRY/WHT WIRE HEATED OXYGEN SENSOR HEATER CTRL HOT AT ALL TIMES HOT IN IAC SOL OSS (+) CAM POS IN IGN COIL 7 IGN COIL 8 FUEL PUMP CTRL EPC SOL INSTRUMENT CLUSTER LT BLU WIRE LT BLU/ORG WIRE LT BLU/RED WIRE LT BLU/YEL WIRE LT GRN WIRE LT GRN/BLK WIRE LT GRN/ORG WIRE M/T A/T 1030 480 729 191 310 MAF SENS IN TP SENS IN MASS AIRFLOW (MAF) SENSOR (IN AIR CLEANER ASSEMBLY) NCA WIRE NOT USED ORG/WHT WIRE PNK/LT BLU WIRE PNK/WHT WIRE PNK/YEL WIRE POWERTRAIN CONTROL MODULE (PCM) (RIGHT SIDE OF ENGINE COMPT) PWR GND IGN COIL 2 RED WIRE RED/BLK WIRE RED/GRN WIRE RED/LT GRN WIRE RED/ORG WIRE RED/PNK WIRE RED/WHT WIRE RED/YEL WIRE SIG RTN BPP SW TAN WIRE TAN/BLK WIRE TAN/LT BLU WIRE TAN/RED WIRE TAN/YEL WIRE VIO/LT GRN WIRE VIO/WHT WIRE VIO/YEL WIRE VPWR FUEL INJ 8 FUEL INJ 6 FUEL INJ 4 FUEL INJ 2 WHT WIRE WHT/BLK WIRE WHT/LT BLU WIRE WHT/RED WIRE WHT/YEL WIRE WOT RELAY YEL/LT BLU WIRE YEL/LT GRN WIRE YEL/RED WIRE
