Wiring diagram engine performance 5.4ls, with 4r70w transmission (1 of 4) for Ford Pickup F150 (1996-2012)

3 4 5 PNK WIRE AIR CONDITIONING SYSTEM BATTERY JUNCTION BOX (LEFT SIDE OF ENGINE COMPT) BLK WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BRN WIRE BRN/ORG WIRE BRN/PNK WIRE CAPACITOR 2 (LEFT FRONT OF ENGINE) CASE GND IGN COIL 1 IGN COIL 5 CENTRAL JUNCTION BOX (UNDER LEFT SIDE OF DASH) COIL ON PLUG DATA LINK (-) DATA LINK (+) DATA LINK CONNECTOR (PARTIAL) (UNDER CENTER OF DASH) 10 2 DIGITAL TRANSMISSION RANGE SENSOR (DTR SENSOR) (LEFT SIDE OF TRANSMISSION) DK BLU WIRE DK GRN/VIO WIRE DK GRN/YEL WIRE DK PNK WIRE FUSE 2 FUSE 29 FUSE 30 GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN RUN OR START IAT FUEL PUMP MON ACCS IGNITION TRANS- FORMER IGNITION TRANS- FORMER CAPACITOR 1 (RIGHT FRONT OF ENGINE) IMCC EVR CTRL (4.6L) IND INSTRUMENT CLUSTER SYSTEM KS SENSOR LT BLU/BLK WIRE LT BLU/YEL WIRE LT GRN WIRE LT GRN/WHT WIRE LT GRN/YEL WIRE LT LT MAF TFT NCA WIRE NOT USED NOT USED CKP(+) CKP(-) OD OFF ORG/ WIRE ORG/BLK WIRE ORG/YEL WIRE PCM POWER DIODE PCM POWER RELAY PNK LT WIRE PNK WIRE PNK/LT BLU WIRE PNK/WHT WIRE POWERTRAIN CONTROL MODULE (PCM) (RIGHT SIDE OF ENGINE COMPT) PWR GND IGN COIL 3 PWR GND TCSS PNK WIRE RADIO NOISE CAPACITOR 1 (RIGHT FRONT OF ENGINE) RADIO NOISE CAPACITOR 2 (LEFT FRONT OF ENGINE) RED WIRE RED/LT GRN WIRE RED/YEL WIRE SHIFT SOL A SHIFT SOL A TCSS PNK WIRE SHIFT SOL B TCIL DLC TAN WIRE TAN/LT BLU WIRE TAN/ORG WIRE TAN/WHT WIRE TCS TO DTR SENSOR (DIAGRAM 4 OF 4) TRANSMISSION CONTROL SWITCH (A/T) TRANSMISSION SYSTEM VIO WIRE VIO/ORG WIRE WHT WIRE WHT/BLK WIRE WHT/LT BLU WIRE WHT/LT GRN WIRE WHT/PNK WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE
