Wiring diagram engine performance 5.0ls, with e4od transmission (4 of 4) for Ford Pickup F150 (1996-2012)

BLK/WHT WIRE BRAKE ON/OFF (BOO) SWITCH (UNDER LEFT SIDE OF I/P) BRN/LT BLU WIRE BRN/LT GRN WIRE BRN/ORG WIRE BRN/WHT WIRE BRN/YEL WIRE DK BLU/YEL WIRE DK GRN/LT GRN WIRE FUSE 13 FUSE PANEL (LEFT SIDE OF I/P) FUSE 17 GRY/BLK WIRE GRY/LT BLU WIRE GRY/RED WIRE GRY/WHT WIRE HEATER CTRL HOT AT ALL TIMES HOT IN RUN OR START LEFT HEATED OXYGEN SENSOR (LOWER LEFT REAR OF ENGINE) LT BLU WIRE LT BLU/ORG WIRE LT BLU/RED WIRE LT BLU/YEL WIRE LT GRN WIRE LT GRN/BLK WIRE LT GRN/ORG WIRE MAF SENS IN TP SENS IN REF VOLT SIG RTN BRAKE ON/OFF MASS AIR FLOW SENSOR (RIGHT FRONT SIDE OF ENGINE COMPARTMENT) NCA WIRE POWERTRAIN CONTROL MODULE (TOP LEFT SIDE OF SAFETY WALL) PPL/YEL WIRE REAR HEATED OXYGEN SENSOR (NEAR CATALYTIC CONVERTER) RED WIRE RED/BLK WIRE RED/LT GRN WIRE RED/WHT WIRE RED/YEL WIRE RIGHT HEATED OXYGEN SENSOR (LOWER RIGHT REAR OF ENGINE) TAN WIRE TAN/BLK WIRE TAN/LT BLU WIRE TAN/RED WIRE TAN/WHT WIRE TRANS- MISSION CONTROL SWITCH (TOP OF STEERING COLUMN) TRANSMISSION RANGE SENSOR (LOWER LEFT SIDE OF TRANSMISSION) WHT WIRE WHT/BLK WIRE WHT/LT BLU WIRE WHT/LT GRN WIRE WHT/ORG WIRE WHT/YEL WIRE YEL WIRE YEL/LT BLU WIRE
