Wiring diagram engine performance 4.6ls for Ford Pickup F150 (1996-2012)

3 4 5 PNK WIRE AIR CONDITIONING SYSTEM BATTERY JUNCTION BOX (LEFT SIDE OF ENGINE COMPT) BLK WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BRN WIRE BRN/ORG WIRE BRN/PNK WIRE CAPACITOR 2 (LEFT FRONT OF ENGINE) CASE GND IGN COIL 1 IGN COIL 5 CENTRAL JUNCTION BOX (UNDER LEFT SIDE OF DASH) COIL ON PLUG DATA LINK (-) DATA LINK (+) DATA LINK CONNECTOR (PARTIAL) (UNDER CENTER OF DASH) 10 2 DIGITAL TRANSMISSION RANGE SENSOR (DTR SENSOR) (LEFT SIDE OF TRANSMISSION) DK BLU WIRE DK GRN/VIO WIRE DK GRN/YEL WIRE DK PNK WIRE FUSE 2 FUSE 29 FUSE 30 GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN RUN OR START IAT FUEL PUMP MON ACCS IGNITION TRANS- FORMER IGNITION TRANS- FORMER CAPACITOR 1 (RIGHT FRONT OF ENGINE) IMCC EVR CTRL (4.6L) IND INSTRUMENT CLUSTER SYSTEM KS SENSOR LT BLU/BLK WIRE LT BLU/YEL WIRE LT GRN WIRE LT GRN/WHT WIRE LT GRN/YEL WIRE LT LT MAF TFT NCA WIRE NOT USED NOT USED CKP(+) CKP(-) OD OFF ORG/ WIRE ORG/BLK WIRE ORG/YEL WIRE PCM POWER DIODE PCM POWER RELAY PNK LT WIRE PNK WIRE PNK/LT BLU WIRE PNK/WHT WIRE POWERTRAIN CONTROL MODULE (PCM) (RIGHT SIDE OF ENGINE COMPT) PWR GND IGN COIL 3 PWR GND TCSS PNK WIRE RED WIRE RED/LT GRN WIRE RED/YEL WIRE SHIFT SOL A SHIFT SOL B TCIL DLC TAN WIRE TAN/LT BLU WIRE TAN/ORG WIRE TAN/WHT WIRE TCS TO DTR SENSOR (DIAGRAM 4 OF 4) TRANSMISSION CONTROL SWITCH (A/T) TRANSMISSION SYSTEM VIO WIRE VIO/ORG WIRE WHT WIRE WHT/BLK WIRE WHT/LT BLU WIRE WHT/LT GRN WIRE WHT/PNK WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE

3 4 5 PNK WIRE BATTERY JUNCTION BOX (LEFT SIDE OF ENGINE COMPT) FUSE 23 BLK/WHT WIRE BREAKOUT TO STARTER RELAY) BRN WIRE BRN/LT GRN WIRE BRN/PNK WIRE BRN/WHT WIRE CRANKSHAFT POSITION (CKP) SENSOR (LOWER FRONT OF ENGINE) CRANKSHAFT POSITION SENSOR SHIELD DIFFERENTIAL PRESSURE FEEDBACK EGR (DPFE) SENSOR (LEFT SIDE OF ENGINE) DK BLU WIRE DK GRN/VIO WIRE DK GRN/YEL WIRE FUEL PUMP RELAY FUEL TANK PRESSURE SENSOR (IN FUEL TANK) FUSE 10 FUSE 18 GRY WIRE GRY/RED WIRE GRY/WHT WIRE HOT AT ALL TIMES INTAKE AIR TEMPERATURE (IAT) SENSOR (ON INTAKE MANIFOLD) INTAKE MANIFOLD RUNNER CONTROL MODULE (4.6L) (RIGHT SIDE OF ENGINE) LT BLU WIRE LT BLU/ORG WIRE NCA WIRE ORG/BLK WIRE ORG/YEL WIRE PNK WIRE PNK/BLK WIRE PNK/LT BLU WIRE PNK/WHT WIRE POWER DISTRIBUTION BOX (LEFT SIDE OF ENGINE COMPT) RED WIRE RED/LT GRN WIRE RED/PNK WIRE RED/YEL WIRE TAN/LT BLU WIRE THROTTLE POSITION (TP) SENSOR (ON THROTTLE BODY) TRANSFER CASE SPEED SENSOR (LEFT REAR OF TRANS) VIO WIRE VIO/ORG WIRE WHT/RED WIRE

BLK WIRE BLK/ORG WIRE BLU WIRE BRN WIRE BRN/LT BLU WIRE BRN/LT GRN WIRE BRN/PNK WIRE BRN/WHT WIRE BRN/YEL WIRE DK BLU/YEL WIRE DK GRN/VIO WIRE DK GRN/YEL WIRE EGR VACUUM REGULATOR SOLENOID (LEFT SIDE OF ENGINE) ELECTRONIC PRESSURE CONTROL SOLENOID EVAP CANISTER PURGE VALVE (LEFT REAR CORNER OF ENGINE COMPT) FUEL INJECTORS GENERIC ELECTRONIC MODULE GRN WIRE GRY/BLK WIRE GRY/RED WIRE GRY/WHT WIRE IDLE AIR CONTROL (IAC) VALVE (ON LEFT SIDE OF INTAKE MANIFOLD) INERTIA FUEL SHUT-OFF SWITCH (UNDER RIGHT SIDE OF DASH) INSTRUMENT CLUSTER SYSTEM LT BLU WIRE LT BLU/ORG WIRE LT GRN/BLK WIRE LT GRN/ORG WIRE LT LT LT NCA WIRE ORG/ WIRE ORG/BLK WIRE ORG/YEL WIRE OUTPUT SHAFT SPEED (OSS) SENSOR (LEFT SIDE OF TRANSMISSION) PNK/BLK WIRE PNK/LT BLU WIRE PNK/WHT WIRE PRESSURE CONTROLLERS RED WIRE RED/LT GRN WIRE RED/PNK WIRE RED/YEL WIRE TAN WIRE TAN/BLK WIRE TAN/LT BLU WIRE TAN/RED WIRE TORQUE CONVERTER CLUTCH SOLENOID TRANSMISSION FLUID TEMPERATURE SENSOR VIO/ORG WIRE VIO/WHT WIRE VIO/YEL WIRE VSS INPUT WHT WIRE WHT/LT BLU WIRE WHT/RED WIRE WHT/YEL WIRE YEL WIRE YEL/WHT WIRE

A/C CLUTCH RELAY BATTERY JUNCTION BOX (ON LEFT SIDE OF ENGINE COMPARTMENT) BLK WIRE BLK/PNK WIRE BLK/WHT WIRE BRN/LT BLU WIRE BRN/LT GRN WIRE BRN/WHT WIRE BRN/YEL WIRE CAMSHAFT POSITION (CMP) SENSOR (ON FRONT OF ENGINE) CENTRAL JUNCTION BOX (UNDER LEFT SIDE OF DASH) CHECK FUEL CAP IND COOLING FAN SYSTEM DIGITAL TRANSMISSION RANGE SENSOR (DTR SENSOR) (LEFT SIDE OF TRANSMISSION) DK BLU/YEL WIRE DK GRN WIRE DK GRN/VIO WIRE FROM DTR SENSOR (DIAGRAM 1 OF 4) FUEL TANK PRESS FUSE 15 FUSE 2 FUSE 20 GRY/BLK WIRE GRY/LT BLU WIRE GRY/RED WIRE GRY/WHT WIRE HEATED OXYGEN SENSOR HEATER CTRL HOT AT ALL TIMES HOT IN IAC SOL OSS (+) CAM POS IN IGN COIL 7 IGN COIL 8 FUEL PUMP CTRL EPC SOL INSTRUMENT CLUSTER LT BLU WIRE LT BLU/ORG WIRE LT BLU/RED WIRE LT BLU/YEL WIRE LT GRN WIRE LT GRN/BLK WIRE LT GRN/ORG WIRE M/T A/T 1030 480 729 191 310 MAF SENS IN TP SENS IN MASS AIRFLOW (MAF) SENSOR (IN AIR CLEANER ASSEMBLY) NCA WIRE NOT USED ORG/WHT WIRE PNK/LT BLU WIRE PNK/WHT WIRE PNK/YEL WIRE POWERTRAIN CONTROL MODULE (PCM) (RIGHT SIDE OF ENGINE COMPT) PWR GND IGN COIL 2 RED WIRE RED/BLK WIRE RED/GRN WIRE RED/LT GRN WIRE RED/ORG WIRE RED/PNK WIRE RED/WHT WIRE RED/YEL WIRE SIG RTN BPP SW TAN WIRE TAN/BLK WIRE TAN/LT BLU WIRE TAN/RED WIRE TAN/YEL WIRE VIO/LT GRN WIRE VIO/WHT WIRE VIO/YEL WIRE VPWR FUEL INJ 8 FUEL INJ 6 FUEL INJ 4 FUEL INJ 2 WHT WIRE WHT/BLK WIRE WHT/LT BLU WIRE WHT/RED WIRE WHT/YEL WIRE YEL/LT BLU WIRE YEL/LT GRN WIRE YEL/RED WIRE
