A/c circuit, vehicles built on or after 6/24/96 for Ford Pickup F150 (1996-2012)

A/C CLUTCH CYCLING PRESSURE SWITCH (RIGHT REAR CORNER OF ENGINE COMPT) A/C CLUTCH DIODE A/C COMPRESSOR CLUTCH SOLENOID A/C PRESSURE CUT OFF SWITCH (RIGHT SIDE OF ENGINE COMPT) BLEND DOOR ACTUATOR (BEHIND CENTER OF I/P) BLEND DOOR POTENTIOMETER BLK WIRE BLK/YEL WIRE BLOWER MOTOR BLOWER MOTOR RESISTOR BLOWER MOTOR SWITCH BLOWER RELAY BLOWER/ FLASHER RELAY BLOCK (BEHIND CENTER OF I/P) BLU WIRE BRN/ORG WIRE BRN/YEL WIRE COLD FUNCTION SELECTOR SWITCH HI (PART OF FUNCTION SELECTOR SWITCH) MED HI MED LO HOT AT ALL TIMES POWER DISTRIBUTION BOX FUSE 23 HOT IN RUN FUSE 5 HOT IN RUN JUNCTION BOX FUSE/ RELAY PANEL FUSE 24 ILLUM LT BLU WIRE LT BLU/PNK WIRE LT GRN WIRE LT GRN/WHT WIRE ORG/BLK WIRE PANEL, FLOOR OFF PANEL FLOOR FLR, DEF NORM A/C DEF MAX A/C PANEL, FLOOR OFF PANEL FLOOR NORM A/C FLR, DEF DEF MAX A/C PNK WIRE POWERTRAIN CONTROL MODULE (PCM) (RIGHT SIDE OF ENGINE COMPT) PPL RED WIRE WARM WHT WIRE YEL WIRE YEL/RED WIRE
