Car Wiring Diagrams for Trunk release circuit for Ford Mustang VII (2022-2024)

BATTERY JUNCTION BOX (BJB) BLK/BLU WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BODY CONTROL MODULE (BCM) BRN/BLU WIRE BRN/WHT WIRE CAN (+) COMPUTER DATA LINES SYSTEM DECKLID LIFTGLASS (FET) DEMAND LP/ BATT SAVE RELAY (FET) FUSE 7 GRN WIRE GRY WIRE GRY/YEL WIRE HOT AT ALL TIMES INSTRUMENT PANEL CLUSTER (IPC) LUGGAGE COMPARTMENT LAMP LUGGAGE COMPARTMENT LID LATCH LUGGAGE COMPARTMENT LID RELEASE SWITCH MICRO - TRUNK AJAR TRUNK RELEASE TRUNK SWITCH UPPER LIFTGATE LATCH VIO/GRY WIRE WHT WIRE WHT/BLU WIRE WHT/RED WIRE YEL/GRN WIRE
