Ford Mustang VI facelift (2017-2023) left pedestrian crash sensor Wiring diagram
This page shows the only wiring diagram for the component.left pedestrian crash sensor, which is found in the car Ford Mustang VI facelift (2017-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left pedestrian crash sensor (1 of 1)
5.0L
BLK WIRE
BLU WIRE
BLU/BRN WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/RED WIRE
BRN/WHT WIRE
BTS SIG
BTS VREF
CENTER PEDESTRIAN CRASH SENSOR
CLOCKSPRING
COMPUTER DATA LINES SYSTEM
COUPE
DRIVER AIR BAG
DRIVER DOOR SIDE IMPACT SENSOR
DRIVER SIDE AIR BAG
ENS
GRN/BLU WIRE
GRN/ORG WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRY/BRN WIRE
GRY/YEL WIRE
INDICATOR
LEFT "B" PILLAR SIDE IMPACT SENSOR
LEFT PEDESTRIAN CRASH SENSOR
NCA WIRE
OCCUPANT CLASSIFICATION SYSTEM MODULE (OCSM)
OFF
PAD
PASSENGER AIR BAG DEACTIVATION (PAD) INDICATOR
PASSENGER DOOR SIDE IMPACT SENSOR
PASSENGER SIDE AIR BAG
POWERTRAIN CONTROL MODULE (PCM)
RIGHT "B" PILLAR SIDE IMPACT SENSOR
RIGHT SEAT POSITION SENSOR
RUN/START
SHORTING BAR
SHORTING BAR SHORTING BAR
STAGE 1
STAGE 2
VIO/BRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/ORG WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/GRY WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component -> Supplemental restraints circuit (2 of 3) -> LEFT PEDESTRIAN CRASH SENSOR
