Ford Mustang V facelift (2009-2014) pass htd seat req Wiring diagram
This page shows the only wiring diagram for the component.pass htd seat req, which is found in the car Ford Mustang V facelift (2009-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pass htd seat req (1 of 1)
BATTERY JUNCTION BOX (BJB) (RIGHT SIDE OF ENGINE COMPT)
BLK WIRE
BLK/YEL WIRE
BLU/BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIV HTD SEAT REQ
DRIVER HEATED SEAT RELAY
DRIVER HEATED SEAT SWITCH PASSENGER HEATED SEAT SWITCH MS CAN-
GRY WIRE
GRY/BLU WIRE
GRY/ORG WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HOT AT ALL TIMES FUSE 16
HOT IN RUN OR ACC SMART JUNCTION BOX (SJB) (RIGHT KICK PANEL) FUSE 43
HVAC MODULE
LEFT FRONT SEAT BACK REST HEATER MAT
LEFT FRONT SEAT CUSHION HEATER MAT
MS CAN +
PASS HTD SEAT REQ
PASSENGER HEATED SEAT RELAY
RED/ VIO WIRE
RIGHT FRONT SEAT BACK REST HEATER MAT
RIGHT FRONT SEAT CUSHION HEATER MAT
VIO/ORG WIRE
VIO/RED WIRE
WHT/BLU WIRE
YEL/BLU WIRE
Go to component -> Heated seats circuit -> PASS HTD SEAT REQ
