Ford Mustang V facelift (2009-2014) mic + mic shield video + compass + compass - wiring diagram
This page shows the only wiring diagram for the component.mic + mic shield video + compass + compass -, which is found in the car Ford Mustang V facelift (2009-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
mic + mic shield video + compass + compass - wiring diagram (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 VPWR REVERSE GND
1 2 3 4 5 6 7 VPWR
AUTO- DIMMING INTERIOR MIRROR UNIT
BLK WIRE
BLK/VIO WIRE
BLK/YEL WIRE
BLU WIRE
BLU/GRY WIRE
BODY CONTROL MODULE B (RIGHT REAR OF LUGGAGE COMPT)
BRN/VIO WIRE
E/C MIRROR REVERSE SIGNAL
GND VIDEO SHLD
GRY/BLU WIRE
GRY/BRN WIRE
HOT IN START OR RUN FUSE 29
HOT W/ ACCESSORY DELAY RELAY ENERGIZED FUSE 41
INSTRUMENT CLUSTER SYSTEM
MIC + MIC SHIELD VIDEO + COMPASS + COMPASS -
MIC -
NCA WIRE
REAR VIDEO CAMERA (CENTER OF TRUNK LID)
SMART JUNCTION BOX (SJB) (RIGHT KICK PANEL)
SOUND SYSTEMS
VIDEO + VIDEO -
VIDEO+
VIO WIRE
WHT WIRE
WHT/GRN WIRE
WHT/VIO WIRE
YEL/GRN WIRE
Go to component -> Electrochromic mirror circuit, with rear view camera -> MIC + MIC SHIELD VIDEO + COMPASS + COMPASS -
