Power seats circuit for Ford Mustang V (2004-2009)
Power seats circuit
BLK WIRE
BUSSED ELECTRICAL CENTER (BEC) (RIGHT FRONT OF ENGINE COMPARTMENT)
DK GRN WIRE
DRIVER SIDE FRONT SEAT ADJUST SWITCH
FUSE 14
FUSE 15
FWD BACK
HOT AT ALL TIMES
LEFT POWER SEAT MOTOR ASSEMBLY (UNDER DRIVER'S SEAT)
PASSENGER SIDE FRONT SEAT ADJUST SWITCH
RED WIRE
RED/LT BLU WIRE
RED/LT GRN WIRE
RED/WHT WIRE
RIGHT POWER SEAT MOTOR ASSEMBLY (UNDER PASSENGER'S SEAT)
UP/ DOWN FRT
UP/ DOWN RR
WHT WIRE
YEL/LT BLU WIRE
YEL/LT GRN WIRE
YEL/WHT WIRE
