Power mirrors circuit for Ford Mustang V (2004-2009)
Power mirrors circuit
BLK WIRE
DK BLU WIRE
DK GRN WIRE
DOWN UP
EXTERIOR REAR VIEW MIRROR SWITCH
FUSE
HOT AT ALL TIMES
LEFT EXTERIOR REAR VIEW MIRROR (FRONT OF DRIVER`S DOOR)
LEFT RIGHT
LT GRN WIRE
MIRROR MOTOR
ORG/ WIRE
RED WIRE
RIGHT EXTERIOR REAR VIEW MIRROR (FRONT OF PASSENGER`S DOOR)
SMART JUNCTION BOX (SJB) (RIGHT KICK PANEL)
VIO WIRE
YEL WIRE
