Passive anti-theft circuit for Ford Mustang V (2004-2009)

Passive anti-theft circuit

Get access

1 2 3 4 RF PWR RF GND TX-SIG RX-SIG BLK WIRE BUSSED ELECTRICAL CENTER (BEC) (RIGHT FRONT OF ENGINE COMPT) COMPUTER DATA LINES SYSTEM GRY/ORG WIRE HOT IN START OR RUN HS CAN + HS CAN - TX OUT RX IN LT GRN WIRE LT GRN/YEL WIRE NCA WIRE PASSIVE ANTI-THEFT TRANSCEIVER (IN STEERING COLUMN) PNK/LT GRN WIRE POWER DISTRIBUTION SYSTEM POWERTRAIN CONTROL MODULE (RIGHT FRONT OF ENGINE COMPT) RED WIRE RED/YEL WIRE SMART JUNCTION BOX (SJB) (RIGHT KICK PANEL) FUSE 19 STARTER RELAY WHT/LT GRN WIRE YEL WIRE
