Ford Mustang V (2004-2009) stoplamp switch 1 Wiring diagram

4.0L ABS CONTROL MODULE AUTOMATIC TRANS- MISSION AUXILIARY RELAY BOX 1 (5.4L) (RIGHT SIDE OF ENGINE COMPT) BLK WIRE BUSSED ELECTRICAL CENTER (BEC) (RIGHT FRONT OF ENGINE COMPT) CHARGE AIR COOLER PUMP RELAY CLIMATE CONTROL MODULE INSTRUMENT CLUSTER COIL ON PLUG (COP) 1 COIL ON PLUG (COP) 2 COIL ON PLUG (COP) 3 COIL ON PLUG (COP) 4 COIL ON PLUG (COP) 5 COIL ON PLUG (COP) 6 COIL ON PLUG (COP) 7 COIL ON PLUG (COP) 8 DATA LINK CONNECTOR (DLC) DK GRN WIRE EXCEPT 4.0L EXCEPT 4.0L TO IGNITION TRANSFORMER CAPACITOR 1) FROM FUSE 16 (DIAGRAM 4 OF 4) FROM FUSE 41 (DIAGRAM 2 OF 4) FROM FUSE 47 (DIAGRAM 2 OF 4) FUSE 10 FUSE 15 FUSE 15 (EXCEPT 5.4L) FUSE 18 FUSE 19 FUSE 39 FUSE 40 FUSE 42 FUSE 59 FUSE 63 FUSE 64 FUSE 68 FUSE 8 GRY/LT BLU WIRE GRY/ORG WIRE HIGH SPEED ENGINE COOLING FAN RELAY IGNITION COIL IGNITION TRANSFORMER CAPACITOR IGNITION TRANSFORMER CAPACITOR 1 IGNITION TRANSFORMER CAPACITOR 2 INSTRUMENT CLUSTER PASSIVE ANTI-THEFT TRANSCEIVER LOW CURRENT BOARD LOW SPEED ENGINE COOLING FAN RELAY LT GRN WIRE LT GRN/RED WIRE LT GRN/VIO WIRE NCA WIRE OVERHEAD CONSOLE PASSENGER SIDE FRONT SEAT ADJUST SWITCH POWER POINT POWERTRAIN CONTROL MODULE (PCM) RED WIRE RED/WHT WIRE RED/YEL WIRE REVERSE LOCKOUT SOLENOID (5.4L) SMART JUNCTION BOX (SJB) (RIGHT KICK PANEL) STOPLAMP SWITCH 1 TAN/BLK WIRE TO BUSSED ELECTRICAL CENTER (BEC) FUSE 67 (DIAGRAM 4 OF 4) TO BUSSED ELECTRICAL CENTER) TO FUSE 67 (DIAGRAM 4 OF 4) TO IGNITION SWITCH (DIAGRAM 4 OF 4) TO PCM POWER DIODE, (DIAGRAM 2 OF 4) TRANSMISSION SHIFT SELECTOR VIO WIRE VIO/WHT WIRE WHT/LT BLU WIRE
