Ford Mustang V (2004-2009) passenger map light Wiring diagram
This page shows the only wiring diagram for the component.passenger map light, which is found in the car Ford Mustang V (2004-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger map light (1 of 1)
BLK WIRE
BLK/LT BLU WIRE
BLK/WHT WIRE
BRN/WHT WIRE
BUSSED ELECTRICAL CENTER (BEC) (RIGHT FRONT OF ENGINE COMPT)
DIMMER
DOME LAMP RTN DOME
DRIVER DR AJAR SWITCH
DRIVER MAP LIGHT
FUSE
GRY/LT BLU WIRE
HOT AT ALL TIMES
ILLUM
ILLUMINATION DIMMER SWITCH
INTERIOR
LEFT FRONT DOOR AJAR SWITCH (REAR OF LEFT FRONT DOOR)
LEFT FRONT POWER WINDOW MOTOR (FRONT OF LEFT FRONT DOOR)
LOW CURRENT BOARD
LT BLU/BLK WIRE
LT GRN/BLK WIRE
LT GRN/YEL WIRE
LUGGAGE COMPARTMENT LAMP
LUGGAGE COMPARTMENT LID AJAR SWITCH (CENTER OF LUGGAGE COMPARTMENT LID)
ORG/RED WIRE
OVERHEAD CONSOLE
PASSENGER DR AJAR SWITCH
PASSENGER MAP LIGHT
RIGHT FRONT DOOR AJAR SWITCH (REAR OF RIGHT FRONT DOOR)
RIGHT FRONT POWER WINDOW MOTOR (FRONT OF RIGHT FRONT DOOR)
SHORT DROP
SMART JUNCTION BOX (SJB) (RIGHT KICK PANEL)
SW RTN PANEL DIM PANEL DIM REF
TAN WIRE
TAN/BLK WIRE
TRUNK AJAR SW
VIO/YEL WIRE
WHT/YEL WIRE
YEL/LT GRN WIRE
Go to component -> Courtesy lamps circuit -> PASSENGER MAP LIGHT
