Ford Mustang V (2004-2009) left front door ajar switch Wiring diagram
This page shows the only wiring diagram for the component.left front door ajar switch, which is found in the car Ford Mustang V (2004-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front door ajar switch (1 of 1)
5.4L
ANTI- THEFT HORN
ANTI-THEFT INHIBIT SWITCH
ANTI-THEFT LUGGAGE COMPARTMENT SWITCH
BLK WIRE
CLUTCH PEDAL POSITION SWITCH DEACTIVATOR SWITCH
CONVERTIBLE TOP AJAR SWITCH
DRIVER SIDE FRONT SEAT ADJUST SWITCH
ELECTRO- CHROMATIC INSIDE MIRROR UNIT
EXTERIOR REAR VIEW MIRROR SWITCH DRIVER SIDE DOOR LOCK SWITCH
LEFT FRONT DOOR AJAR SWITCH
LEFT FRONT LUMBAR ADJUST SWITCH
LEFT FRONT MASTER WINDOW ADJUST SWITCH POWER WINDOW MOTOR
LEFT FRONT SEAT BACK HEATER
LEFT OUTBOARD LUGGAGE COMPARTMENT SUBWOOFER AMPLIFIER
LEFT REAR SIDE LAMP
LUGGAGE COMPARTMENT LAMP
LUGGAGE COMPARTMENT LID AJAR SWITCH
LUGGAGE COMPARTMENT LID RELEASE SOLENOID HIGH MOUNTED STOP LAMP
MANUAL TRANSMISSION
NCA WIRE
ORG/ WIRE
OVERHEAD CONSOLE
PARKING BRAKE SWITCH
PASSENGER SIDE DOOR LOCK SWITCH
PASSENGER SIDE FRONT SEAT ADJUST SWITCH
PASSENGER SIDE WINDOW ADJUST SWITCH
POWER POINT
REAR WINDOW ADJUST SWITCH
RIGHT FRONT DOOR AJAR SWITCH
RIGHT FRONT POWER WINDOW MOTOR
RIGHT FRONT SEAT BACK HEATER
RIGHT INBOARD LUGGAGE COMPARTMENT SUBWOOFER AMPLIFIER
RIGHT REAR PARK/ STOP/TURN LAMP 1
RIGHT REAR PARK/ STOP/TURN LAMP 2
RIGHT REAR POWER WINDOW MOTOR
RIGHT REAR SIDE LAMP LICENSE PLATE LAMP
RIGHT REVERSING LAMP
RIGHT TAIL LAMP
SMART JUNCTION BOX
TRANSMISSION SHIFT SELECTOR
WINDSHIELD WASHER PUMP MOTOR
WINDSHIELD WIPER MOTOR
Go to component: -> Ground distribution circuit (3 of 3) -> LEFT FRONT DOOR AJAR SWITCH
