Ford Mustang V (2004-2009) ignition transformer capacitor 2 Wiring diagrams
This page contains all the electrical diagrams for the component. ignition transformer capacitor 2, in which he is found in the car Ford Mustang V (2004-2009). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
ignition transformer capacitor 2 wiring diagram (1 of 2)
4.6L, 5.4L
5.4L
A/C CLUTCH FIELD COIL
AUDIO UNIT
BLK WIRE
BLK/ORG WIRE
BUSSED ELECTRICAL CENTER (BEC) (RIGHT FRONT OF ENGINE COMPT)
DRIVER SAFETY BELT BUCKLE SWITCH
DRIVER SEAT POSITION SENSOR
DUAL PRESSURE SWITCH
IGNITION TRANSFORMER CAPACITOR 1
IGNITION TRANSFORMER CAPACITOR 2
LEFT FRONT CHANNEL SUBWOOFER AMPLIFIER
LEFT REAR PARK/STOP/ TURN LAMP 1
LEFT REAR PARK/STOP/ TURN LAMP 2
LEFT REVERSING LAMP
LEFT TAIL LAMP
LT BLU WIRE
NCA WIRE
OCCUPANT CLASSIFICATION SENSOR MODULE
ORG/ WIRE
PARKING BRAKE SWITCH POWER POINT
PASSENGER SAFETY BELT BUCKLE SWITCH
PASSENGER SIDE DOOR LOCK SWITCH
PASSENGER SIDE WINDOW ADJUST SWITCH
RESTRAINTS CONTROL MODULE
RIGHT FRONT CHANNEL SUBWOOFER AMPLIFIER
RIGHT FRONT DOOR AJAR SWITCH
RIGHT FRONT POWER WINDOW MOTOR
SATELLITE RADIO RECEIVER
SECONDARY FUEL PUMP DRIVER MODULE
SHIELD
SMART JUNCTION BOX
Go to component -> Ground distribution circuit (2 of 3) -> IGNITION TRANSFORMER CAPACITOR 2
ignition transformer capacitor 2 wiring diagram (2 of 2)
4.0L
ABS CONTROL MODULE
AUTOMATIC TRANS- MISSION
AUXILIARY RELAY BOX 1 (5.4L) (RIGHT SIDE OF ENGINE COMPT)
BLK WIRE
BUSSED ELECTRICAL CENTER (BEC) (RIGHT FRONT OF ENGINE COMPT)
CHARGE AIR COOLER PUMP RELAY
CLIMATE CONTROL MODULE INSTRUMENT CLUSTER
COIL ON PLUG (COP) 1
COIL ON PLUG (COP) 2
COIL ON PLUG (COP) 3
COIL ON PLUG (COP) 4
COIL ON PLUG (COP) 5
COIL ON PLUG (COP) 6
COIL ON PLUG (COP) 7 COIL ON PLUG (COP) 8
DATA LINK CONNECTOR (DLC)
DK GRN WIRE
EXCEPT 4.0L
EXCEPT 4.0L TO IGNITION TRANSFORMER CAPACITOR 1)
FROM FUSE 16 (DIAGRAM 4 OF 4)
FROM FUSE 41 (DIAGRAM 2 OF 4)
FROM FUSE 47 (DIAGRAM 2 OF 4)
FUSE 10
FUSE 15
FUSE 15 (EXCEPT 5.4L)
FUSE 18
FUSE 19
FUSE 39
FUSE 40
FUSE 42
FUSE 59
FUSE 63
FUSE 64
FUSE 68
FUSE 8
GRY/LT BLU WIRE
GRY/ORG WIRE
HIGH SPEED ENGINE COOLING FAN RELAY
IGNITION COIL
IGNITION TRANSFORMER CAPACITOR
IGNITION TRANSFORMER CAPACITOR 1
IGNITION TRANSFORMER CAPACITOR 2
INSTRUMENT CLUSTER PASSIVE ANTI-THEFT TRANSCEIVER
LOW CURRENT BOARD
LOW SPEED ENGINE COOLING FAN RELAY
LT GRN WIRE
LT GRN/RED WIRE
LT GRN/VIO WIRE
NCA WIRE
OVERHEAD CONSOLE
PASSENGER SIDE FRONT SEAT ADJUST SWITCH
POWER POINT
POWERTRAIN CONTROL MODULE (PCM)
RED WIRE
RED/WHT WIRE
RED/YEL WIRE
REVERSE LOCKOUT SOLENOID (5.4L)
SMART JUNCTION BOX (SJB) (RIGHT KICK PANEL)
STOPLAMP SWITCH 1
TAN/BLK WIRE
TO BUSSED ELECTRICAL CENTER (BEC) FUSE 67 (DIAGRAM 4 OF 4)
TO BUSSED ELECTRICAL CENTER)
TO FUSE 67 (DIAGRAM 4 OF 4)
TO IGNITION SWITCH (DIAGRAM 4 OF 4)
TO PCM POWER DIODE, (DIAGRAM 2 OF 4)
TRANSMISSION SHIFT SELECTOR
VIO WIRE
VIO/WHT WIRE
WHT/LT BLU WIRE
Go to component -> Power distribution circuit (3 of 4) -> IGNITION TRANSFORMER CAPACITOR 2
