Trunk, tailgate, fuel door circuits for Ford Mustang IV facelift (1998-2004)
Trunk, tailgate, fuel door circuits
BLK WIRE
BRN WIRE
BRN/WHT WIRE
CENTRAL JUNCTION BOX (BEHIND DASH, LEFT OF STEERING COLUMN)
FUSE 25
GENERIC ELECTRONIC MODULE (BELOW LEFT SIDE OF DASH)
HOT AT ALL TIMES
LUGGAGE COMPARTMENT LAMP
LUGGAGE COMPARTMENT LID RELAY
LUGGAGE COMPARTMENT LID RELEASE SOLENOID (ON LATCH ASSEMBLY)
LUGGAGE COMPARTMENT LID RELEASE SWITCH
ORG/ WIRE
PNK/LT GRN WIRE
RELAY BOX (BEHIND LEFT SIDE OF DASH, NEAR CENTRAL JUNCTION BOX)
VIO WIRE
VIO/YEL WIRE
WHT WIRE
YEL WIRE
