Car Wiring Diagrams for Charging circuit for Ford Mustang IV facelift (1998-2004)

BATTERY BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT) BLK WIRE BLK/ORG WIRE CENTRAL JUNCTION BOX (CJB) (BEHIND DASH, LEFT OF STEERING COLUMN) CHARGE INDICATOR 490 OHMS FUSE 20 FUSE LINK A FUSE LINK B GENERATOR GRN WIRE GRY WIRE HOT IN RUN FUSE 5 INSTRU- MENT CLUSTER LT GRN/RED WIRE PNK/BLK WIRE POWER DISTRIBUTION SYSTEM RED WIRE STARTER MOTOR WHT WIRE YEL WIRE YEL/WHT WIRE
