Back-up lamps circuit for Ford Mustang IV facelift (1998-2004)
Back-up lamps circuit
A/T
BLK WIRE
BLK/PNK WIRE
CENTRAL JUNCTION BOX (BEHIND DASH, LEFT OF STEERING COLUMN)
DIGITAL TRANSMISSION RANGE (DTR)
FUSE 11
GENERIC ELECTRONIC MODULE (BELOW LEFT SIDE OF DASH)
HOT IN RUN
LEFT REVERSING LAMP
M/T
ORG/ WIRE
REVERSING LAMP SWITCH
RIGHT REVERSING LAMP
SENSOR (ON LEFT REAR SIDE OF TRANSMISSION)
