4.6l, cooling fan circuit for Ford Mustang IV facelift (1998-2004)
4.6l, cooling fan circuit
AUXILIARY FUSE BOX (RIGHT SIDE OF ENGINE COMPT) FUSE 31
BLK WIRE
BLK/ORG WIRE
BLU WIRE
CENTRAL JUNCTION BOX (BEHIND DASH, LEFT OF STEERING COLUMN)
DK BLU WIRE
ENGINE COOLING FAN MOTOR
FUSE 1
FUSE 26
FUSE 34
GRN WIRE
HIGH SPEED FAN CONTROL RELAY
HOT AT ALL TIMES
HOT IN RUN OR START
LOW SPEED FAN CONTROL RELAY
LT BLU WIRE
LT DK
LT GRN/VIO WIRE
ORG/ WIRE
PCM POWER RELAY
POWERTRAIN CONTROL MODULE (PCM) (BEHIND RIGHT KICK PANEL)
RED WIRE
RED/ORG WIRE
RELAY CONTROL
VIO WIRE
WHT/LT BLU WIRE
YEL WIRE
