3.8l, cooling fan circuit for Ford Mustang IV facelift (1998-2004)
3.8l, cooling fan circuit
BLK WIRE
BLK/ORG WIRE
BLU WIRE
CENTRAL JUNCTION BOX (BEHIND DASH, LEFT OF STEERING COLUMN)
DK BLU WIRE
ENGINE COOLING FAN MOTOR (BEHIND RADIATOR)
FUSE 1
FUSE 26
FUSE 34
HOT AT ALL TIMES
HOT IN RUN OR START
LOW SPEED COOLANT FAN RELAY
ORG/ WIRE
PCM POWER RELAY
POWERTRAIN CONTROL MODULE (PCM) (BEHIND RIGHT KICK PANEL)
RED WIRE
RELAY CONTROL
WHT/LT BLU WIRE
YEL WIRE
