Ford Mustang IV facelift (1998-2004) function selector switch assembly restraints control module wiring diagram
This page shows the only wiring diagram for the component.function selector switch assembly restraints control module, which is found in the car Ford Mustang IV facelift (1998-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
function selector switch assembly restraints control module wiring diagram (1 of 1)
4.6L
BATTERY JUNCTION BOX
BLK WIRE
BRN WIRE
CENTRAL JUNCTION BOX (BEHIND DASH, LEFT OF STEERING COLUMN)
CIRCUIT BREAKER 43
CONSTANT CONTROL RELAY IGNITION COIL
CONSTANT CONTROL RELAY IGNITION TRANSFORMER CAPACITOR
CONVERTIBLE TOP SWITCH
COUPE CONVERTIBLE
DAYTIME RUNNING LAMPS MODULE (BEHIND CENTER OF DASH)
DK DK
DK GRN WIRE
ELECTRONIC FLASHER MODULE
FROM FUSE 3 (BATTERY JUNCTION BOX) (DIAGRAM 1 OF 3)
FROM FUSE 4 (BATTERY JUNCTION BOX) (DIAGRAM 1 OF 3)
FROM FUSE 5 (BATTERY JUNCTION BOX) (DIAGRAM 1 OF 3)
FRONT PASSENGER WINDOW/DOOR LOCK SWITCH
FRONT WASHER PUMP MOTOR RELAY
FUNCTION SELECTOR SWITCH ASSEMBLY RESTRAINTS CONTROL MODULE
FUSE 18
FUSE 20
FUSE 26
FUSE 32
FUSE 36 FUSE 30 FUSE 24
FUSE 6 FUSE 34 FUSE 28
GENERIC ELECTRONIC MODULE
GRN WIRE
GRY WIRE
IGNITION SWITCH
INSTRUMENT CLUSTER
LOCK OFF
LT BLU WIRE
LT GRN WIRE
MASTER WINDOW/ DOOR LOCK/ UNLOCK SWITCH MASTER WINDOW/ DOOR LOCK/ UNLOCK SWITCH
MODULE
NCA WIRE
ORG/ WIRE
PASSIVE ANTI-THEFT TRANSCEIVER 3.8L MODULE
PNK WIRE
RADIO
RED WIRE
RELAY BOX (LEFT SIDE OF DASH)
RUN WIRE
STARTING/ CHARGING SYSTEM (BEHIND LEFT SIDE OF DASH)
TO IGNITION SWITCH (DIAGRAM 3 OF 3)
TRANSMISSION CONTROL SWITCH
VIO WIRE
WHT WIRE
WHT/LT BLU WIRE
WINDSHIELD WIPER MOTOR
WIPER HIGH/LOW RELAY
WIPER RUN/PARK RELAY
YEL WIRE
Go to component -> Power distribution circuit (2 of 3) -> FUNCTION SELECTOR SWITCH ASSEMBLY RESTRAINTS CONTROL MODULE
