Instrument illumination circuit for Ford Mustang IV (1993-1998)
Instrument illumination circuit
3 BULBS
A/C- HEATER CONTROL ILLUMINATION
ASHTRAY ILLUMINATION
BLK WIRE
BRN WIRE
CD PLAYER ILLUMINATION
CLOCK
COURTESY LIGHTS CIRCUIT
DOME
FOG LAMP SWITCH
FUSE 13
FUSE 5
FUSE 8
GROUND
GRY WIRE
HOT AT ALL TIMES
I/P FUSE PANEL (BEHIND I/P, LEFT OF STEERING COLUMN)
ILLUM
ILLUM INPUT
ILLUMINATION
INSTRUMENT CLUSTER
LT BLU WIRE
LT BLU/RED WIRE
LT GRN/YEL WIRE
MAIN LIGHT SWITCH
OFF HEAD PARK
RADIO
RADIO ILLUMINATION
REAR WINDOW DEFROST CONTROL SWITCH
RED WIRE
TAN/WHT WIRE
TRANSMISSION CONTROL SWITCH (TCS)
W/ CD PLAYER
W/ PREMIUM OR SUPER SOUND
W/O PREMIUM OR SUPER SOUND
