Car Wiring Diagrams for Heater circuit for Ford Mustang IV (1993-1998)

BLK WIRE BLOWER MOTOR BLOWER RESISTORS BLOWER SWITCH BRN/ORG WIRE DK BLU WIRE FUSE 17 HEATER CONTROL ASSEMBLY HOT IN RUN I/P FUSE PANEL LT GRN WIRE LT GRN/WHT WIRE OFF MIX FLOOR VENT DEF ORG/ WIRE ORG/BLK WIRE YEL/RED WIRE
