Ford Mustang IV (1993-1998) vss input boo sw input wiring diagram
This page shows the only wiring diagram for the component.vss input boo sw input, which is found in the car Ford Mustang IV (1993-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
vss input boo sw input wiring diagram (1 of 1)
2200 OHMS OHMS
7 8 9 IGN
A/T M/T
ANTI/THEFT CONTROLLER MODULE AND/OR REMOTE KEYLESS ENTRY MODULE
BRAKE ON/OFF (BOO) SWITCH (ON TOP OF
BRAKE PRES SW INPUT
BRAKE PRESSURE SW (NEAR CLUTCH PEDAL SUPPORT)
CLOCKSPRING ASSEMBLY
COAST
CRUISE CTRL SW INPUT CRUISE CTRL SW GND
DEACTIVATOR SW (ON CLUTCH PEDAL SUPPORT)
DK GRN/ORG 848 WIRE
DK GRN/ORG WIRE
FUSE 9 FUSE
GROUND
GRY/BLK 679 WIRE
GRY/BLK WIRE
HORN RELAY
HORN SW
HOT AT ALL TIMES
HOT IN ACC OR RUN
I/P FUSE PANEL
LT BLU/BLK 151 WIRE
LT BLU/BLK WIRE
LT GRN 511 WIRE
LT GRN WIRE
LT GRN/RED WIRE
NCA WIRE
OFF
OHMS
ORG 636 WIRE
ORG/ WIRE
PNK/ORG 676 WIRE
PNK/ORG WIRE
RED WIRE
RED/LT GRN WIRE
SET/ ACCEL RESUME
SPEED CONTROL AMPLIFIER (BEHIND I/P NEAR LEFT COWL)
SPEED CONTROL SW ASSEMBLY
VEHICLE SPEED SENSOR (LEFT REAR OF TRANSMISSION)
VSS INPUT BOO SW INPUT
WHT/PPL 296 WIRE
WHT/PPL WIRE
YEL/LT GRN WIRE
Go to component -> Cruise control circuit -> VSS INPUT BOO SW INPUT
