Ford Mustang IV (1993-1998) one touch down power window module Wiring diagram
This page shows the only wiring diagram for the component.one touch down power window module, which is found in the car Ford Mustang IV (1993-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram one touch down power window module (1 of 1)
A/C- HEATER CONTROL ILLUMINATION
AIR BAG DIAGNOSTIC CONNECTOR
AIR BAG DIAGNOSTIC MONITOR
ANTI-THEFT HOOD SWITCH
ANTI-THEFT TRANSCEIVER MODULE (TATS ONLY)
BASE
BLK WIRE
BRAKE FLUID LEVEL SWITCH
CD PLAYER RADIO
CLOCK
CONVERTIBLE ONLY
CONVERTIBLE W/ REMOTE/KEYLESS ENTRY
CONVERTIBLE W/O REMOTE/KEYLESS ENTRY
COUPE
COUPE W/ POWER WINDOWS/DOOR LOCKS W/ REMOTE/KEYLESS ENTRY
COUPE W/ POWER WINDOWS/DOOR LOCKS W/O REMOTE/KEYLESS ENTRY
COUPE W/ REMOTE/KEYLESS
COUPE W/O POWER WINDOWS/DOOR LOCKS
COUPE W/O REMOTE/KEYLESS
DATA LINK CONNECTOR (3.8L ONLY)
ELECTRONIC FLASHER
ENGINE COMPT LAMP
ENTRY
FUEL GAUGE SENDER
FUEL PUMP
HI MOUNT STOP/ LUGGAGE COMPT LAMP ASSEMBLY
IGNITION SWITCH
INSTRUMENT CLUSTER
LEFT BACKUP LAMP
LEFT DOOR DISARM SWITCH
LEFT DOOR DISARM SWITCH POWER MIRROR SWITCH
LEFT LICENSE LAMP
LEFT REAR PARK/STOP/ TURN LAMPS
LEFT REAR SIDE MARKER LAMP
LOW ENGINE OIL WARNING RELAY BLOWER MOTOR SWITCH
LOWER RELAY
MASTER WINDOW/DOOR LOCK CONTROL SWITCH
NCA WIRE
ONE TOUCH DOWN POWER WINDOW MODULE
POWER MIRROR SWITCH
RADIO
RAISE RELAY
REAR WINDOW DEFROST CONTROL SWITCH
REMOTE/KEYLESS ENTRY MODULE
RIGHT LICENSE LAMP
RIGHT REAR PARK/STOP/ TURN LAMPS RIGHT BACKUP LAMP
RIGHT REAR SIDE MARKER LAMP
SHIFT LOCK ACTUATOR
SUPER SOUND BLOWER MOTOR RESISTOR ASSEMBLY
TRANSMISSION CONTROL SWITCH
TRUNK LID RELEASE SOLENOID DECK LID ANTI- THEFT SWITCH
WARNING CHIME MODULE
WINDSHIELD WIPER MOTOR
WIPER CONTROL SWITCH
Go to component -> Ground distribution circuit (2 of 3) -> ONE TOUCH DOWN POWER WINDOW MODULE
