Ford Mustang IV (1993-1998) driver seat control switch Wiring diagram
This page shows the only wiring diagram for the component.driver seat control switch, which is found in the car Ford Mustang IV (1993-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver seat control switch (1 of 1)
BLK WIRE
BLK/WHT WIRE
DOWN UP
DRIVER SEAT CONTROL SWITCH
DRIVER'S SEAT MOTOR ASSEMBLY
ENTIRE SEAT
FUSE BOX
FWD/RWD MOTOR
HEIGHT MOTOR
HOT AT ALL TIMES POWER SEAT FUSE
LEFT POWER LUMBAR COMPRESSOR MOTOR
LEFT POWER SEAT LUMBAR SWITCH
LT BLU WIRE
LT BLU/WHT WIRE
NCA WIRE
REAR OF SEAT
RED WIRE
RED/LT BLU WIRE
RIGHT POWER LUMBAR COMPRESSOR MOTOR
RIGHT POWER SEAT LUMBAR SWITCH
RWD FWD
WHT WIRE
YEL WIRE
YEL/WHT WIRE
Go to component -> Power & lumbar seat circuit -> DRIVER SEAT CONTROL SWITCH
