Ford Mustang IV (1993-1998) 16 15 13 data + data - reprogramming pwr supply wiring diagram
This page shows the only wiring diagram for the component.16 15 13 data + data - reprogramming pwr supply, which is found in the car Ford Mustang IV (1993-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
16 15 13 data + data - reprogramming pwr supply wiring diagram (1 of 1)
16 15 13 DATA + DATA - REPROGRAMMING PWR SUPPLY
4.6L 3.8L
6 5 BUS + BUS -
AIRBAG DIAGNOSTIC MONITOR (BEHIND CENTER OF I/P)
BLK WIRE
BLK/WHT WIRE
DATA LINK CONNECTOR (DLC) (RIGHT OF STEERING COLUMN)
HOT AT ALL TIMES I/P FUSE PANEL FUSE 8
LT BLU/WHT WIRE
PNK/LT BLU WIRE
POWERTRAIN CONTROL MODULE (PCM) (BEHIND RIGHT COWL PANEL)
PPL
PPL PPL
TAN/ORG WIRE
YEL WIRE
