Ford Mustang Mach-E I (2020-2024) vio/org Wiring diagrams
This page contains all the electrical diagrams for the component. vio/org, in which he is found in the car Ford Mustang Mach-E I (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
vio/org wiring diagram (31 of 74)
2/1
BATTERY ENERGY CONTROL MODULE (BECM)
BATTERY JUNCTION BOX (BCMC)
BATTERY JUNCTION BOX (BJB)
BLK/BLU WIRE
BLU WIRE
BLU/GRN WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BCM)
BRN/BLU WIRE
BRN/WHT WIRE
BRN/YEL WIRE
DIRECT CURRENT/ DIRECT CURRENT (DC/DC) CONVERTER CONTROL MODULE
ETHERNET
EV CAN -
FUSE 186
FUSE 21
GATEWAY MODULE A (GWM)
GRN WIRE
GRN/BLU WIRE
GRN/ORG WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/ORG WIRE
GRY/RED WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
HS CAN FD -
IMAGE PROCESSING MODULE A (IPMA)
MICRO -
MS CAN +
REMOTE DATA LINK CONNECTOR (DLC)
SECONDARY ON-BOARD DIAGNOSTIC CONTROL MODULE C (SOBDMC)
TELEMATICS CONTROL UNIT (TCU) MODULE
VBATT
VIO/BRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/ORG WIRE
WHT/VIO WIRE
YEL/ORG WIRE
Go to component -> Computer data lines circuit (1 of 5) -> VIO/ORG WIRE
vio/org wiring diagram (32 of 74)
ANTI-LOCK BRAKE SYSTEM (ABS) MODULE
BLU WIRE
BLU/GRN WIRE
BLU/ORG WIRE
CENTER CONSOLE
DRIVER STATUS MONITOR CAMERA MODULE (CMR)
ETHERNET
EV CAN -
EVAC, FILL
GEAR SHIFT MODULE (GSM)
GRN WIRE
GRN/BLU WIRE
GRN/ORG WIRE
GRY/BLU WIRE
GRY/ORG WIRE
HS CAN FD -
OFF BOARD CHARGE CONTROLLER (OBCC)
POWER STEERING CONTROL MODULE (PSCM)
POWERTRAIN CONTROL MODULE (PCM)
SECONDARY ON-BOARD DIAGNOSTIC CONTROL MODULE A (SOBDMA)
SYNC MODULE (APIM)
VEHICLE DYNAMICS CONTROL MODULE (VDM)
VIO/BRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/VIO WIRE
YEL/ORG WIRE
Go to component -> Computer data lines circuit (2 of 5) -> VIO/ORG WIRE
vio/org wiring diagram (33 of 74)
AIR CONDITIONING CONTROL MODULE (ACCM)
BATTERY ENERGY CONTROL MODULE B (BECMB)
BLU WIRE
BLU/GRN WIRE
ETHERNET
EV CAN -
EXCEPT GT
GRN WIRE
GRN/BLU WIRE
GRN/ORG WIRE
GRY/BLU WIRE
GRY/ORG WIRE
HEADLAMP CONTROL MODULE (HCM)
INSTRUMENT PANEL CLUSTER (IPC)
OCCUPANT CLASSIFICATION SYSTEM MODULE (OCSM)
PEDESTRIAN ALERT CONTROL MODULE (PACM)
RESTRAINTS CONTROL MODULE (RCM)
SECONDARY ON-BOARD DIAGNOSTIC CONTROL MODULE B (SOBDMB)
STEERING COLUMN CONTROL MODULE (SCCM)
VIO/BRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
VIO/WHT WIRE
WHT WIRE
WHT/GRN WIRE
Go to component -> Computer data lines circuit (3 of 5) -> VIO/ORG WIRE
vio/org wiring diagram (34 of 74)
AUDIO DIGITAL SIGNAL PROCESSING (DSP) MODULE)
AUDIO FRONT CONTROL MODULE (ACM)
BLU/GRN WIRE
CENTER CONSOLE
DRIVER DOOR MODULE (DDM)
GRN/BLU WIRE
GRY/BLU WIRE
GRY/ORG WIRE
MS CAN +
REMOTE FUNCTION ACTUATOR MODULE
TELEMATICS CONTROL UNIT (TCU) MODULE
VIO/ORG WIRE
VIO/WHT WIRE
W/O PHONE AS KEY
WHT/GRN WIRE
WIRELESS ACCESSORY CHARGING MODULE (WACM)
Go to component -> Computer data lines circuit (4 of 5) -> VIO/ORG WIRE
vio/org wiring diagram (35 of 74)
BLK WIRE
DRIVER FRONT SEAT MODULE
FRONT TRUNK RELEASE MODULE
GRY/ORG WIRE
HEATING VENTILATION, AIR CONDITIONING (HVAC) CONTROL MODULE
LEFT FRONT DOOR LATCH CONTROL MODULE (DCME)
LEFT REAR DOOR LATCH CONTROL MODULE (DCMG)
MS CAN +
PASSENGER DOOR MODULE (PDM)
REAR GATE TRUNK MODULE (RGTM)
RIGHT FRONT DOOR LATCH CONTROL MODULE (DCMF)
RIGHT REAR DOOR LATCH CONTROL MODULE (DCMH)
VIO/ORG WIRE
W/ HEATED SEATS
W/ POWER LIFTGATE
W/O HEATED SEATS
W/O POWER LIFTGATE
Go to component -> Computer data lines circuit (5 of 5) -> VIO/ORG WIRE
vio/org wiring diagram (36 of 74)
BATTERY JUNCTION BOX (BJB)
BLK/GRY WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLU/GRY WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
BRN/BLU WIRE
BRN/RED WIRE
COMPUTER DATA LINES SYSTEM
DRIVER DOOR MODULE (DDM)
ETHERNET
FUSE 133
FUSE 14
FUSE 50
FUSE 7
GRN/BLU WIRE
GRN/VIO WIRE
GRY WIRE
GRY/BRN WIRE
GRY/ORG WIRE
GRY/RED WIRE
HEAT (+)
HEATED WIPER PARK RELAY
HEATER
HOT AT ALL TIMES
IMAGE PROCESSING MODULE A (IPMA)
LEFT EXTERIOR MIRROR
LEFT WINDSHIELD HEATED WIPER
MS CAN +
NCA WIRE
ORG/ WIRE
PASSENGER DOOR MODULE (PDM)
REAR WINDOW DEFROST GRID
REAR WINDOW DEFROST RELAY
RED WIRE
RIGHT EXTERIOR MIRROR
SIGRTN
VBATT
VIO WIRE
VIO/ORG WIRE
VPWR
WHT WIRE
WHT/ORG WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Defoggers circuit -> VIO/ORG WIRE
vio/org wiring diagram (37 of 74)
AFT
BATTERY JUNCTION BOX (BJB)
BLK/GRY WIRE
BLU/BRN WIRE
BRN/GRN WIRE
BRN/RED WIRE
DEFLATE
DOWN
FORE/
FUSE 30
GRN WIRE
GRN/VIO WIRE
GRY/BRN WIRE
GRY/ORG WIRE
GRY/VIO WIRE
HEIGHT
HORIZONTAL
HOT AT ALL TIMES
INCLINE
INFLATE
LEFT FRONT SEAT CONTROL SWITCH
LEFT FRONT SEAT HEIGHT ADJUSTMENT MOTOR
LEFT FRONT SEAT POWER LUMBAR MOTOR
LEFT FRONT SEAT RECLINER MOTOR
LEFT FRONT SEAT TRACK MOTOR
LUMBAR
RECLINE
VIO/BRN WIRE
VIO/ORG WIRE
VIO/RED WIRE
WHT/BRN WIRE
YEL/BLU WIRE
YEL/VIO WIRE
Go to component -> Driver power seat circuit -> VIO/ORG WIRE
vio/org wiring diagram (38 of 74)
BATTERY JUNCTION BOX (BJB)
BLK/GRY WIRE
BLK/VIO WIRE
BLU/BRN WIRE
BLU/ORG WIRE
COMPUTER DATA LINES SYSTEM
DRV HEATED SEAT ELEMENT
DRV HTR FEED
DRV ST NTC SENSE
FUSE 39
GRY/BLU WIRE
GRY/ORG WIRE
HEATING VENTILATION, AIR CONDITIONING (HVAC) CONTROL MODULE
HOT AT ALL TIMES
LEFT FRONT SEAT BACKREST HEATER MAT
LEFT FRONT SEAT CUSHION HEATER MAT
MS CAN +
NCA WIRE
PASS HEATED SEAT ELEMENT
PASS HTR FEED
PASS ST NTC SENSE
RIGHT FRONT SEAT BACKREST HEATER MAT
RIGHT FRONT SEAT CUSHION HEATER MAT
SIGRTN
VIO/ORG WIRE
WHT/RED WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/VIO WIRE
Go to component -> Heated seats circuit -> VIO/ORG WIRE
vio/org wiring diagram (39 of 74)
AFT
BATTERY JUNCTION BOX (BJB)
BLK/GRY WIRE
BLU/BRN WIRE
BRN/GRN WIRE
DEFLATE
DOWN
FORE/
FUSE 31
GRN WIRE
GRN/VIO WIRE
GRY/BRN WIRE
GRY/ORG WIRE
GRY/VIO WIRE
HEIGHT
HORIZONTAL
HOT AT ALL TIMES
INCLINE
INFLATE
LUMBAR
RECLINE
RIGHT FRONT SEAT CONTROL SWITCH
RIGHT FRONT SEAT HEIGHT ADJUSTMENT MOTOR
RIGHT FRONT SEAT POWER LUMBAR MOTOR
RIGHT FRONT SEAT RECLINER MOTOR
RIGHT FRONT SEAT TRACK MOTOR
VIO/BRN WIRE
VIO/ORG WIRE
VIO/RED WIRE
WHT/BRN WIRE
WHT/RED WIRE
YEL/BLU WIRE
YEL/VIO WIRE
Go to component -> Passenger power seat circuit -> VIO/ORG WIRE
vio/org wiring diagram (40 of 74)
BLK WIRE
BLK/WHT WIRE
BLU/BRN WIRE
BLU/GRY WIRE
BLU/ORG WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/WHT WIRE
CANISTER VENT
CENTER PEDESTRIAN CRASH SENSOR
COMPUTER DATA LINES SYSTEM
DRIVER KNEE AIR BAG
GRN WIRE
GRN/ORG WIRE
GRN/VIO WIRE
GRY WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/ORG WIRE
LEFT "C" PILLAR)
LEFT FRONT IMPACT SEVERITY SENSOR
LEFT SEAT TRACK POSITION SENSOR
LEFT SECOND ROW SIDE IMPACT SENSOR
NCA WIRE
OCS OUT
PASSENGER AIR BAG
RCM OUT
RIGHT FRONT DOOR SIDE IMPACT SENSOR
RIGHT SEAT TRACK POSITION SENSOR
RIGHT SECOND ROW SEAT MOUNTED AIR BAG
RIGHT SECOND ROW SIDE IMPACT SENSOR
SHORTING BAR
STAGE 1
STAGE 2
VBATT
VIO/GRN WIRE
VIO/ORG WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLU WIRE
WHT/ORG WIRE
WHT/VIO WIRE
YEL WIRE
YEL/BLU WIRE
YEL/GRY WIRE
YEL/ORG WIRE
YEL/RED WIRE
YEL/VIO WIRE
Go to component -> Supplemental restraints circuit (3 of 4) -> VIO/ORG WIRE
