Ford Mustang Mach-E I (2020-2024) right temperature blend door actuator Wiring diagram
This page shows the only wiring diagram for the component.right temperature blend door actuator, which is found in the car Ford Mustang Mach-E I (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right temperature blend door actuator (1 of 1)
BATTERY JUNCTION BOX (BJB)
BLK/VIO WIRE
BLOWER MOTOR CONTROL MODULE
BLU WIRE
BLU/ORG WIRE
BRN/GRN WIRE
BRN/WHT WIRE
COOLING FAN RELAY
EVAPORATOR TEMPERATURE SENSOR
FRONT BLOWER MOTOR RELAY
FUSE 13
FUSE 47
GRN/BLU WIRE
GRN/BRN WIRE
GRY WIRE
GRY/BLU WIRE
GRY/BRN WIRE
HOT AT ALL TIMES
HOT W/ RUN/START RELAY 2 ENERGIZED
HUMIDITY
IN-VEHICLE TEMPERATURE/ HUMIDITY SENSOR
LEFT FOOTWELL AIR DISCHARGE TEMPERATURE SENSOR
LEFT REGISTER AIR DISCHARGE TEMPERATURE SENSOR
PWM
RIGHT FOOTWELL AIR DISCHARGE TEMPERATURE SENSOR
RIGHT REGISTER AIR DISCHARGE TEMPERATURE SENSOR
RIGHT TEMPERATURE BLEND DOOR ACTUATOR
SIG RTN
TEMP 1
TEMP 2
TEMP 3
VIO/BRN WIRE
VIO/GRN WIRE
VPWR
VREF
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/ORG WIRE
WHT/VIO WIRE
YEL/GRY WIRE
Go to component -> Automatic a/c circuit (2 of 4) -> RIGHT TEMPERATURE BLEND DOOR ACTUATOR
