Ford Mustang Mach-E I (2020-2024) right liftgate anti-pinch detection switch Wiring diagram
This page shows the only wiring diagram for the component.right liftgate anti-pinch detection switch, which is found in the car Ford Mustang Mach-E I (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right liftgate anti-pinch detection switch (1 of 1)
BLK/GRN WIRE
BLK/VIO WIRE
BLU/BRN WIRE
BLU/RED WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
FUSE 11
GRN/BLU WIRE
GRN/ORG WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRY/ORG WIRE
GRY/VIO WIRE
HANDSFREE LIFTGATE ACTUATION MODULE
HOT AT ALL TIMES
ILLUM
INTRUSION/ INCLINATION SENSOR
LEFT LIFTGATE ANTI-PINCH DETECTION SWITCH
LEFT POWER LIFTGATE MOTOR (LEFT SIDE OF LIFTGATE)
LIFTGATE AJAR
LIFTGATE LATCH ASSEMBLY
LIFTGATE RELEASE
LIFTGATE RELEASE (FET)
LIFTGATE RELEASE SWITCH
LIN 02
NCA WIRE
POSITION SENSOR
POWER LIFTGATE SWITCH
RIGHT LIFTGATE ANTI-PINCH DETECTION SWITCH
SENSOR PWR
SENSOR RTN
SENSOR SIG 1
SENSOR SIG 2
VBATT
WHT/BLU WIRE
WHT/GRN WIRE
YEL WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component -> Power liftgate circuit (2 of 2) -> RIGHT LIFTGATE ANTI-PINCH DETECTION SWITCH
