Ford Mustang Mach-E I (2020-2024) rear parking aid camera Wiring diagram
This page shows the only wiring diagram for the component.rear parking aid camera, which is found in the car Ford Mustang Mach-E I (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear parking aid camera (1 of 1)
BATTERY JUNCTION BOX (BJB)
BLK WIRE
BLK/BLU WIRE
BLU/ORG WIRE
BODY CONTROL MODULE (BCM)
COAX
COMPUTER DATA LINES SYSTEM
DISPLAY
ETHERNET
FIXED REAR VIEW CAMERA
FRONT CAMERA
FRONT PARKING AID CAMERA
FRONT, SIDE REAR VIEW CAMERA
FUSE 17
FUSE 25
HOT AT ALL TIMES
HOT W/ RUN/START RELAY 2 ENERGIZED
HS CAN FD -
IMAGE PROCESSING MODULE A (IPMA)
LEFT SIDE PARKING AID CAMERA
LH SIDE CAMERA
REAR CAMERA
REAR PARKING AID CAMERA
RED WIRE
RH SIDE CAMERA
RIGHT SIDE PARKING AID CAMERA
SYNC MODULE (APIM) (LOWER CENTER OF DASH)
VBATT
VPWR
WHT/BLU WIRE
WHT/ORG WIRE
WHT/VIO WIRE
YEL/ORG WIRE
Go to component -> All around vision camera circuit -> REAR PARKING AID CAMERA
