Ford Mustang Mach-E I (2020-2024) lr radar gnd Wiring diagram
This page shows the only wiring diagram for the component.lr radar gnd, which is found in the car Ford Mustang Mach-E I (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lr radar gnd (1 of 1)
BATTERY JUNCTION BOX (BJB)
BLIS INDICATOR
BLK WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLU/BRN WIRE
BLU/ORG WIRE
BODY CONTROL MODULE (BCM)
BRN/RED WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DRIVER DOOR MODULE (DDM)
FUSE 14
FUSE 25
FUSE 7
GRN/VIO WIRE
GRN/WHT WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
HOT W/ RUN/START RELAY 2 ENERGIZED
HS CAN FD -
IMAGE PROCESSING MODULE A (IPMA)
LEDS
LEFT EXTERIOR MIRROR
LEFT EXTERIOR MIRROR BLIND SPOT (BLIS)/ CROSS TRAFFIC ALERT (CTA) LED
LEFT REAR SIDE OBSTACLE DETECTION CONTROL MODULE (SOD-L)
LR RADAR GND
LR RADAR PWR
MS CAN +
NCA WIRE
PASSENGER DOOR MODULE (PDM)
RIGHT EXTERIOR MIRROR
RIGHT EXTERIOR MIRROR BLIND SPOT (BLIS)/ CROSS TRAFFIC ALERT (CTA) LED
RIGHT REAR SIDE OBSTACLE DETECTION CONTROL MODULE (SOD-R)
RR RADAR CAN -
RR RADAR GND
RR RADAR PWR
VBATT
VIO/BRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
VPWR
WHT/ORG WIRE
WHT/RED WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component -> Blind spot information system circuit -> LR RADAR GND
