Ford Mustang Mach-E I (2020-2024) lin 05 Wiring diagrams
This page contains all the electrical diagrams for the component. lin 05, in which he is found in the car Ford Mustang Mach-E I (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram lin 05 (1 of 2)
ANTI-LOCK BRAKES SYSTEM
ANTI-THEFT SYSTEM
AUTO LAMP
BACK LTG (FET)
BACK LTG 2 (FET)
BLU WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BCM) (RIGHT SIDE OF DASH)
BOO
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/RED WIRE
BRN/YEL WIRE
BSI (FET)
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL, INSTRUMENT CLUSTER SYSTEMS
DOOR LOCK LED (FET)
DOOR LOCKS SYSTEM
ENABLE/DISABLE WIRELESS CHARGE (FET)
ENG SW
FUSE 3
GRN WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/RED WIRE
GRY/VIO WIRE
GRY/WHT WIRE
HAZARD
HEADLIGHTS SYSTEM
HI BEAM (FET) WAKE UP (FET)
HIGH CURRENT BATTERY JUNCTION BOX (BJB)
HOOD AJAR
HORN RELAY (FET)
HORN RELAY INPUT
HORNS, ENGINE CONTROLS SYSTEMS
HORNS, POWER DISTRIBUTION SYSTEMS
HOT AT ALL TIMES
INT LTG (FET) ECU DRV (PCM WAKEUP) (FET)
INTERIOR LIGHTS, POWER DISTRIBUTION SYSTEMS
LF DRL LPS (FET)
LF HI BEAM (FET)
LF LED TURN OUTAGE
LF LOW BEAM (FET)
LF POSITION LPS (FET) STOP/TURN RIGHT
LF TURN LPS (FET)
LIN 04
LIN 05
LIN 07
LIN 10
LIN 11
LIN 12
MICRO -
MIRRORS SYSTEM
NOT USED NOT USED
PCM WAKE (FET) (NOT USED) FUEL PUMP ON (FET)
POWER DISTRIBUTION SYSTEM
POWER WINDOWS SYSTEM
RED WIRE
RETURN
RF DRL LPS (FET)
RF LED TURN OUTAGE
RF LO BEAM (FET)
RF POSITION LPS (FET)
RF TURN LPS (FET)
RUN/ACC (FET)
RUN/START
RUN/START (FET)
SOUND SYSTEMS
START BUTTON (FET)
START/STOP)
STARTING/CHARGING SYSTEM
STOP/TURN LEFT
SUPPLEMENTAL RESTRAINTS SYSTEM
TRANSMISSIONS SYSTEM
TRANSMISSIONS, COMPUTER DATA LINES SYSTEMS
TRUNK, TAILGATE, FUEL DOORS SYSTEM
VBATT
VIO/BRN WIRE
VIO/GRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
VIO/RED WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
WIPER/WASHER SYSTEM
YEL/BLU WIRE
YEL/GRN WIRE
YEL/ORG WIRE
YEL/RED WIRE
YEL/VIO WIRE
Go to component -> Body control modules circuit (1 of 2) -> LIN 05
Wiring diagram lin 05 (2 of 2)
BATTERY JUNCTION BOX (BJB)
BLK/BLU WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLK/VIO WIRE
BLU WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/RED WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
BRN/RED WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DEFROST
DEFROST IND
DRL CTRL
EXCEPT GT
FROM LF HIGH BEAM (FET) (DIAGRAM 1 OF 2)
FUSE 157
FUSE 158
FUSE 19
FUSE 21
FUSE 22
GRILLE EMBLEM (GT)
GRN WIRE
GRN/BLU WIRE
GRN/BRN WIRE
GRN/ORG WIRE
GRN/WHT WIRE
GRY/BLU WIRE
GRY/WHT WIRE
GRY/YEL WIRE
HB PWR
HEADLAMP SWITCH
HI BEAM RELAY
HIGH BEAM (FET)
HOT AT ALL TIMES
HOT W/ RUN/START RELAY 2 ENERGIZED
INSTRUMENT PANEL CLUSTER (IPC)
LEFT FRONT SUSPENSION HEIGHT SENSOR
LEFT REAR SUSPENSION HEIGHT SENSOR
LIN 05
LIN 07
LIN HCM
LO BEAM
MICRO -
MULTI- FUNCTION SWITCH
OUTAGE
PVT CAN (+)
RF DRL LPS (FET)
RF LED TURN
RF LOW BEAM (FET)
RIGHT FRONT TURN
RIGHT HEADLAMP ASSEMBLY
SIDE MARKER PWR
STEERING COLUMN CONTROL MODULE (SCCM)
TURN OUTAGE
VBATT
VIO/BRN WIRE
VIO/ORG WIRE
VIO/WHT WIRE
VPWR
WHT WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/VIO WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component -> Headlights circuit (2 of 2) -> LIN 05
