Ford Mustang Mach-E I (2020-2024) left frt radar pwr Wiring diagram
This page shows the only wiring diagram for the component.left frt radar pwr, which is found in the car Ford Mustang Mach-E I (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left frt radar pwr (1 of 1)
A/D CHANNEL 1
A/D CHANNEL 2
A/D CHANNEL 3
A/D RETURN
BLK WIRE
BLK/BLU WIRE
BLU/BRN WIRE
BLU/ORG WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/RED WIRE
BRN/YEL WIRE
CLOCKSPRING
COMPUTER DATA LINES SYSTEM
FRT RADAR CAN +
FRT RADAR GND
FRT RADAR PWR
GRN/BLU WIRE
GRN/ORG WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BLU WIRE
HS CAN FD -
ILLUM
ILLUM GND
INSTRUMENT PANEL CLUSTER (IPC)
LEFT FRONT SIDE OBSTACLE DETECTION CONTROL MODULE (SODCMC)
LEFT FRT RADAR GND
LEFT FRT RADAR PWR
LEFT STEERING WHEEL SWITCH
LEFT SWS GND
NCA WIRE
RIGHT FRONT SIDE OBSTACLE DETECTION CONTROL MODULE (SODCMD)
RIGHT FRT RADAR GND
RIGHT FRT RADAR PWR
STEERING COLUMN CONTROL MODULE (SCCM)
VBATT
VIO/GRY WIRE
VPWR
WHT/GRN WIRE
WHT/ORG WIRE
WHT/VIO WIRE
YEL/GRN WIRE
YEL/ORG WIRE
Go to component -> Cruise control circuit (2 of 2) -> LEFT FRT RADAR PWR
