Ford Mustang Mach-E I (2020-2024) handsfree liftgate actuation module Wiring diagrams
This page contains all the electrical diagrams for the component. handsfree liftgate actuation module, in which he is found in the car Ford Mustang Mach-E I (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram handsfree liftgate actuation module (1 of 3)
AIR CONDITIONING CONTROL MODULE (ACCM)
ANTI- THEFT HORN
ANTI-LOCK BRAKE SYSTEM (ABS) MODULE
AUXILIARY STUD BOX
BATTERY JUNCTION BOX (BJB) COOLING FAN RELAY
BLK WIRE
BLOWER MOTOR CONTROL MODULE
BLUETOOTH ANTENNA 6
CENTER CONSOLE USB CHARGE PORT
EVAC, FILL
FUSE 2
FUSE HOLDER 2
GRN WIRE
GRY WIRE
HANDSFREE LIFTGATE ACTUATION MODULE
HAZARD SWITCH
HEATING VENTILATION, AIR CONDITIONING (HVAC) CONTROL MODULE
HIGH MOUNTED STOP LAMP
LEFT HORN
LEFT LICENSE PLATE LAMP
LEFT LIFTGATE LAMP ASSEMBLY
LEFT REAR LAMP ASSEMBLY
LEFT REAR SIDE MARKER LAMP
LEFT WINDSHIELD HEATED WIPER
LIFTGATE LAMP
LIFTGATE RELEASE SWITCH
NCA WIRE
POWER LIFTGATE SWITCH
POWER STEERING CONTROL MODULE (PSCM)
POWERTRAIN CONTROL MODULE (PCM)
REAR WINDOW DEFROST GRID
REVERSING LAMP
RIGHT HEADLAMP ASSEMBLY
RIGHT HORN
RIGHT LICENSE PLATE LAMP
RIGHT REAR SIDE MARKER LAMP
VIO WIRE
W/ REAR FOG LAMPS
WHT WIRE
WINDSHIELD WASHER FLUID LEVEL SENSOR
WINDSHIELD WIPER MOTOR
WIRELESS ACCESSORY CHARGING MODULE (WACM)
Go to component -> Ground distribution circuit (2 of 5) -> HANDSFREE LIFTGATE ACTUATION MODULE
Wiring diagram handsfree liftgate actuation module (2 of 3)
ACCESSORY DELAY RELAY
BATTERY ENERGY CONTROL MODULE B (BECMB)
BLK/VIO WIRE
BLU WIRE
BLU/GRY WIRE
BLU/RED WIRE
BRN/RED WIRE
BSI (FET)
CENTER CONSOLE
CIRCUIT BREAKER 38
COMPUTER DATA LINES SYSTEM
DISPLAY MODULE
DRIVER DOOR MODULE (DDM)
DRIVER STATUS MONITOR CAMERA MODULE (CMR)
ENABLE/ DISABLE WIRELESS CHRG (FET)
FROM HIGH BATTERY JUNCTION BOX (BJB) (DIAGRAM 1 OF 8)
FUSE 10
FUSE 11
FUSE 12
FUSE 14
FUSE 18
FUSE 19
FUSE 4
FUSE 6
FUSE 7
GRN/BLU WIRE
GRN/RED WIRE
HANDSFREE LIFTGATE ACTUATION MODULE
HEADLAMP SWITCH
INTRUSION/ INCLINATION SENSOR
LEFT KEYLESS ENTRY KEYPAD
MICRO -
PASSENGER DOOR MODULE (PDM)
REAR GATE TRUNK MODULE (RGTM)
RED WIRE
REMOTE FUNCTION ACTUATOR (RFA) MODULE
RIGHT FRONT EXTERIOR DOOR LATCH SWITCH
RIGHT REAR INTERIOR DOOR LATCH SWITCH
TELEMATICS CONTROL UNIT (TCU) MODULE
TO FUSE 20 (DIAGRAM 6 OF 8)
TO IGNITION SWITCH (DIAGRAM 6 OF 8)
USED)
VBATT
WHITE LTG (FET)
WHT/GRN WIRE
WHT/RED WIRE
WIRELESS ACCESSORY CHARGING MODULE (WACM)
YEL/RED WIRE
Go to component -> Power distribution circuit (5 of 8) -> HANDSFREE LIFTGATE ACTUATION MODULE
Wiring diagram handsfree liftgate actuation module (3 of 3)
