Ford Mustang Mach-E I (2020-2024) drvr anchor preten + Wiring diagram
This page shows the only wiring diagram for the component.drvr anchor preten +, which is found in the car Ford Mustang Mach-E I (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram drvr anchor preten + (1 of 1)
BATTERY ENERGY CONTROL MODULE (BECM)
BCKL SW
BLK WIRE
BLK/WHT WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/ORG WIRE
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BTS SIG
BTS VREF
CASE GROUND
CENTER SECOND ROW SEAT BELT BUCKLE
COMPUTER DATA LINES SYSTEM
DRV SIDE IM SN FEED
DRV SIDE IM SN RTN
DRVR ANCHOR PRETEN +
ENS
GND BCKL SW
GRN WIRE
GRN/BLU WIRE
GRN/ORG WIRE
GRN/VIO WIRE
GRY/BLU WIRE
GRY/VIO WIRE
GRY/YEL WIRE
INSTRUMENT PANEL CLUSTER (IPC)
LEFT FRONT SEAT BELT BUCKLE
LEFT SEAT BELT ASSEMBLY
LEFT SECOND ROW SEAT BELT BUCKLE
LEFT SECOND ROW SEAT BELT PRETENSIONER
NCA WIRE
OCCUPANT CLASSIFICATION SYSTEM MODULE (OCSM)
OCM PWR
PASS ANCHOR PRETEN +
PASS SIDE IM SN FEED
PASS SIDE IM SN RTN
RESTRAINTS CONTROL MODULE (RCM)
RETURN 54 55 DRV BCKL SW SNS PASS SEAT BUCKLE SW
RIGHT FRONT SEAT BELT BUCKLE SWITCH
RIGHT SECOND ROW SEAT BELT BUCKLE
RIGHT SECOND ROW SEAT BELT PRETENSIONER
TELEMATICS CONTROL UNIT (TCU) MODULE
VIO WIRE
VIO/GRN WIRE
VIO/ORG WIRE
WHT/GRN WIRE
WHT/ORG WIRE
WHT/VIO WIRE
YEL/BLU WIRE
YEL/VIO WIRE
Go to component: -> Supplemental restraints circuit (4 of 4) -> DRVR ANCHOR PRETEN +
