Ford Mustang Mach-E I (2020-2024) driver status monitor camera Wiring diagram
This page shows the only wiring diagram for the component.driver status monitor camera, which is found in the car Ford Mustang Mach-E I (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver status monitor camera (1 of 1)
BLK/BLU WIRE
BLU/GRN WIRE
BLU/ORG WIRE
BODY CONTROL MODULE (BCM)
CAMERA
COAX
COMPUTER DATA LINES SYSTEM
DRIVER STATUS MONITOR CAMERA
DRIVER STATUS MONITOR CAMERA MODULE (CMR)
DRIVER STATUS MONITOR LED
DRV SIDE IR LED +
FUSE 18
GRY/ORG WIRE
HOT AT ALL TIMES
HS CAN FD -
IR LED +
PASS SIDE IR LED -
VPWR
WHT/GRN WIRE
YEL/ORG WIRE
YEL/RED WIRE
Go to component -> Driver monitoring system circuit -> DRIVER STATUS MONITOR CAMERA
