Ford Mustang Mach-E I (2020-2024) center pedestrian crash sensor Wiring diagram
This page shows the only wiring diagram for the component.center pedestrian crash sensor, which is found in the car Ford Mustang Mach-E I (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram center pedestrian crash sensor (1 of 1)
BLK WIRE
BLK/WHT WIRE
BLU/BRN WIRE
BLU/GRY WIRE
BLU/ORG WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/WHT WIRE
CANISTER VENT
CENTER PEDESTRIAN CRASH SENSOR
COMPUTER DATA LINES SYSTEM
DRIVER KNEE AIR BAG
GRN WIRE
GRN/ORG WIRE
GRN/VIO WIRE
GRY WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/ORG WIRE
LEFT "C" PILLAR)
LEFT FRONT IMPACT SEVERITY SENSOR
LEFT SEAT TRACK POSITION SENSOR
LEFT SECOND ROW SIDE IMPACT SENSOR
NCA WIRE
OCS OUT
PASSENGER AIR BAG
RCM OUT
RIGHT FRONT DOOR SIDE IMPACT SENSOR
RIGHT SEAT TRACK POSITION SENSOR
RIGHT SECOND ROW SEAT MOUNTED AIR BAG
RIGHT SECOND ROW SIDE IMPACT SENSOR
SHORTING BAR
STAGE 1
STAGE 2
VBATT
VIO/GRN WIRE
VIO/ORG WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLU WIRE
WHT/ORG WIRE
WHT/VIO WIRE
YEL WIRE
YEL/BLU WIRE
YEL/GRY WIRE
YEL/ORG WIRE
YEL/RED WIRE
YEL/VIO WIRE
Go to component -> Supplemental restraints circuit (3 of 4) -> CENTER PEDESTRIAN CRASH SENSOR
