Ford Mustang Mach-E I (2020-2024) cabin coolant temperature sensor Wiring diagrams
This page contains all the electrical diagrams for the component. cabin coolant temperature sensor, in which he is found in the car Ford Mustang Mach-E I (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram cabin coolant temperature sensor (1 of 2)
AAT
ACPT
AIR CONDITIONING (A/C) PRESSURE TRANSDUCER
AMBIENT AIR TEMPERATURE (AAT) SENSOR
BLK WIRE
BLK/GRN WIRE
BLU WIRE
BLU/WHT WIRE
CABIN COOLANT TEMPERATURE SENSOR
CABIN HEATER COOLANT PUMP
CHCDV
COMPUTER DATA LINES SYSTEM
COOLING FAN MOTOR
EV CAN -
FC-V
GRN/BLU WIRE
GRY/ORG WIRE
GRY/YEL WIRE
HCP
PCMRC
POWERTRAIN CONTROL MODULE (PCM)
PWR GND
SIGRTN
VIO/BRN WIRE
VIO/ORG WIRE
VREF
YEL WIRE
YEL/BLU WIRE
YEL/GRY WIRE
YEL/VIO WIRE
Go to component -> Automatic a/c circuit (4 of 4) -> CABIN COOLANT TEMPERATURE SENSOR
Wiring diagram cabin coolant temperature sensor (2 of 2)
BATTERY JUNCTION BOX (BJB)
BLK WIRE
BLK/GRN WIRE
BLK/VIO WIRE
BLU WIRE
CABIN COOLANT TEMPERATURE SENSOR
CABIN HEATER COOLANT DIVERTER VALVE
CABIN HEATER COOLANT PUMP
CHCDV
COMPUTER DATA LINES SYSTEM
COOLING FAN MOTOR
COOLING FAN RELAY
ECT 2
EV CAN -
FC-V
FUSE 24
FUSE 47
FUSE 8
GRN/BLU WIRE
GRY/ORG WIRE
GRY/YEL WIRE
HCP
HOT AT ALL TIMES
HOT W/ PCM POWER RELAY ENERGIZED
HOT W/ RUN/START RELAY 2 ENERGIZED
ISP-R
POWERTRAIN CONTROL MODULE (PCM)
PWR GND
SIGRTN
VIO/GRN WIRE
YEL WIRE
YEL/GRY WIRE
YEL/VIO WIRE
Go to component -> Cooling fan circuit -> CABIN COOLANT TEMPERATURE SENSOR
