Ford Mustang Mach-E I (2020-2024) auxiliary stud box Wiring diagrams
This page contains all the electrical diagrams for the component. auxiliary stud box, in which he is found in the car Ford Mustang Mach-E I (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram auxiliary stud box (1 of 2)
AIR CONDITIONING CONTROL MODULE (ACCM)
ANTI- THEFT HORN
ANTI-LOCK BRAKE SYSTEM (ABS) MODULE
AUXILIARY STUD BOX
BATTERY JUNCTION BOX (BJB) COOLING FAN RELAY
BLK WIRE
BLOWER MOTOR CONTROL MODULE
BLUETOOTH ANTENNA 6
CENTER CONSOLE USB CHARGE PORT
EVAC, FILL
FUSE 2
FUSE HOLDER 2
GRN WIRE
GRY WIRE
HANDSFREE LIFTGATE ACTUATION MODULE
HAZARD SWITCH
HEATING VENTILATION, AIR CONDITIONING (HVAC) CONTROL MODULE
HIGH MOUNTED STOP LAMP
LEFT HORN
LEFT LICENSE PLATE LAMP
LEFT LIFTGATE LAMP ASSEMBLY
LEFT REAR LAMP ASSEMBLY
LEFT REAR SIDE MARKER LAMP
LEFT WINDSHIELD HEATED WIPER
LIFTGATE LAMP
LIFTGATE RELEASE SWITCH
NCA WIRE
POWER LIFTGATE SWITCH
POWER STEERING CONTROL MODULE (PSCM)
POWERTRAIN CONTROL MODULE (PCM)
REAR WINDOW DEFROST GRID
REVERSING LAMP
RIGHT HEADLAMP ASSEMBLY
RIGHT HORN
RIGHT LICENSE PLATE LAMP
RIGHT REAR SIDE MARKER LAMP
VIO WIRE
W/ REAR FOG LAMPS
WHT WIRE
WINDSHIELD WASHER FLUID LEVEL SENSOR
WINDSHIELD WIPER MOTOR
WIRELESS ACCESSORY CHARGING MODULE (WACM)
Go to component -> Ground distribution circuit (2 of 5) -> AUXILIARY STUD BOX
Wiring diagram auxiliary stud box (2 of 2)
ANTI-LOCK BRAKE SYSTEM (ABS) MODULE
AUXILIARY RELAY BOX
AUXILIARY STUD BOX
BATTERY
BATTERY MONITORING SENSOR
BATTERY MOUNTED FUSE LINK (BMFL)
BLK WIRE
BLK/GRY WIRE
BLK/VIO WIRE
BLU/GRN WIRE
BLU/RED WIRE
BODY CONTROL MODULE (BCM)
BRN/RED WIRE
CHARGE STATUS INDICATOR (CSI)
FRONT BLOWER MOTOR RELAY
FRONT TRUNK RELEASE RELAY
FRONT TRUNK RELEASE RELAY 1
FRONT TRUNK RELEASE RELAY 2
FRONT WIPER RUN/ PARK RELAY
FUSE 1
FUSE 129
FUSE 16
FUSE 17
FUSE 2
FUSE 200
FUSE 28
FUSE 29
FUSE 3
FUSE 4
FUSE 46
FUSE 91
FUSE 93
FUSE HOLDER 1
FUSE HOLDER 2
GRN/RED WIRE
GRY WIRE
GRY/RED WIRE
GRY/YEL WIRE
HEATED WIPER PARK RELAY
HI BEAM RELAY
HIGH CURRENT BATTERY JUNCTION BOX (BJB)
HORN RELAY
NCA WIRE
POWER STEERING CONTROL MODULE (PSCM)
REAR WASHER RELAY
REAR WINDOW DEFROST RELAY
RED WIRE
RED/WHT (OR RED) WIRE
RED/YEL WIRE
SECONDARY ON-BOARD DIAGNOSTIC CONTROL MODULE A (SOBDMA)
SPARE RELAY
TO BODY CONTROL MODULE (BCM) (DIAGRAM 5 OF 8)
TO BODY CONTROL MODULE (BCM) (DIAGRAM 7 OF 8)
TO FUSE 159 (DIAGRAM 2 OF 8)
VIO/WHT WIRE
YEL/RED WIRE
Go to component -> Power distribution circuit (1 of 8) -> AUXILIARY STUD BOX
