Multicontour seats circuit for Ford Mondeo V facelift (2019-2023)
Multicontour seats circuit
BATTERY JUNCTION BOX (BJB)
BLK/BLU WIRE
BLK/GRN WIRE
BODY CONTROL MODULE (BCM)
COMPUTER DATA LINES SYSTEM
DEFLATE
DEMAND LP/ BATTERY SAVER RELAY
DOWN
DRIVER MULTI-CONTOUR SEAT MODULE (SCMG)
DRIVER SIDE FRONT SEAT CONTROL SWITCH
EXCEPT HYBRID
FEED
FUSE 53
GRN WIRE
GRN/VIO WIRE
GRY/BRN WIRE
GRY/ORG WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HS 3 CAN -
INFLATE
LEFT MULTI-CONTOUR CONTROL PUMP
MODE SELECT
MS CAN +
MULTI- CONTOUR SEAT RELAY
PASSENGER MULTI-CONTOUR SEAT MODULE (SCMH)
PASSENGER SIDE FRONT SEAT CONTROL SWITCH
RIGHT MULTI-CONTOUR CONTROL PUMP
RTN
SYNC MODULE (APIM)
VBATT
VIO/ORG WIRE
WHT WIRE
WHT/ORG WIRE
YEL WIRE
YEL/GRN WIRE
