Electronic power steering circuit, hybrid for Ford Mondeo V facelift (2019-2023)
Electronic power steering circuit, hybrid
BATTERY JUNCTION BOX (BJB)
BLK/VIO WIRE
BRN/RED WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
FUSE 19
GRN WIRE
GRN/ORG WIRE
GRY/BLU WIRE
HIGH CURRENT BATTERY JUNCTION BOX (BJB)
HOT AT ALL TIMES
HOT IN RUN OR START
INSTRUMENT PANEL CLUSTER (IPC) MODULE
MEGA FUSE 6
MOTOR
POWER STEERING CONTROL MODULE (PSCM)
PWR GND
VBATT
VPWR
WHT WIRE
