Hybrid cooling fan circuit, hybrid for Ford Mondeo V facelift (2019-2023)
Hybrid cooling fan circuit, hybrid
BATTERY CHARGER CONTROL MODULE (BCCM)
BATTERY ENERGY CONTROL MODULE (BECM)
BATTERY JUNCTION BOX (BJB)
BLK/VIO WIRE
BLU WIRE
BLU/RED WIRE
COMPUTER DATA LINES SYSTEM
FAN FB
FAN PWM
FUSE 35
FUSE 36
FUSE 50
FUSE 52
FUSE 64
FUSION
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRY/VIO WIRE
HIGH VOLTAGE BATTERY CHARGER COOLING FAN
HIGH VOLTAGE BATTERY COOLING FAN
HOT AT ALL TIMES
HOT W/ TCM POWER RELAY ENERGIZED
PHEV HEV
PWR GND
RED WIRE
VBATT
VIO WIRE
VPWR
WHT WIRE
WHT/GRN WIRE
WHT/VIO WIRE
