Ford Mondeo V facelift (2019-2023) shift interlock, transmissions systems wiring diagram
This page shows the only wiring diagram for the component.shift interlock, transmissions systems, which is found in the car Ford Mondeo V facelift (2019-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
shift interlock, transmissions systems wiring diagram (1 of 1)
AIR CONDITIONING, HEADLIGHTS SYSTEMS
APA ENABLE/DISABLE SW
AUTO LAMP SENSOR
AUTO LAMP SENSOR RTN
AUTOLAMP ON
BACK LIGHT (FET)
BLU WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BCM) (LEFT END OF DASH)
BRN WIRE
BRN/GRN WIRE
BRN/VIO WIRE
BRN/WHT WIRE
BRN/YEL WIRE
BSI (FET) PCM WAKE UP SUPPLY
DIMMER DN INPUT
DIMMER UP INPUT
DOOR LOCK
DOOR LOCKS, ANTI-THEFT SYSTEMS
ENG SW
GRN WIRE
GRN/BRN WIRE
GRN/WHT WIRE
GRY/BRN WIRE
GRY/YEL WIRE
HAZARD SW FOG LAMP ON
HEAD/PARK LAMPS OFF
HEADLIGHTS SYSTEM
HEADLIGHTS, EXTERIOR LIGHTS SYSTEMS
HORN RELAY INPUT
HORNS SYSTEM
IP RELEASE SW
K LINE
LIN 07
LOW BEAM REQ
MICRO -
NAVIGATION SYSTEM
PA ENABLE/DISABLE SW
PARK AID IND (FET)
PARK LAMPS ON
POWER DISTRIBUTION SYSTEM
PRT 2 ANTENNA HI (HB)
PRT 2 ANTENNA LO (HB)
REAR FOG LAMPS ON
SHIFT INTERLOCK, TRANSMISSIONS SYSTEMS
START BUTTON (FET)
START/STOP 2
TRUNK, TAILGATE, FUEL DOORS SYSTEM
VIO WIRE
VIO/ORG WIRE
VIO/WHT WIRE
WHITE LIGHT (FET)
WHT WIRE
WHT/VIO WIRE
YEL WIRE
YEL/BLU WIRE
YEL/ORG WIRE
Go to component -> Body control modules circuit, except hybrid (3 of 3) -> SHIFT INTERLOCK, TRANSMISSIONS SYSTEMS
