2.5l flex fuel, a/t circuit for Ford Mondeo V (2014-2019)

BATTERY JUNCTION BOX (BJB) BLK/GRN WIRE BLK/YEL WIRE BLU/GRN WIRE BLU/GRY WIRE BODY CONTROL MODULE (BCM) BPP BPS BRN/BLU WIRE BRN/GRN WIRE BRN/WHT WIRE BRN/YEL WIRE CAN (-) CAN (+) COMPUTER DATA LINES SYSTEM ENGINE CONTROLS SYSTEM FUSE 54 FUSE 7 GRN/BLU WIRE GRN/BRN WIRE GRN/VIO WIRE GRN/WHT WIRE GRY WIRE GRY/ORG WIRE GRY/YEL WIRE HOT AT ALL TIMES HOT W/ PCM POWER RELAY ENERGIZED HS CAN+ LPC MICRO - OSS + OSS/TR GND OSS/TR VPWR POWERTRAIN CONTROL MODULE (PCM) PWR GND SIG RTN SSA SSB SSC SSD SSE SST+ TCC TCS TFT TFT SIG RTN TR-P TRS TSPC TSS TURBINE SHAFT SPEED (TSS) SENSOR VIO WIRE VIO/GRN WIRE VIO/ORG WIRE VIO/WHT WIRE VPWR WHT WIRE WHT/BLU WIRE WHT/ORG WIRE WHT/RED WIRE YEL/VIO WIRE

BATTERY JUNCTION BOX (BJB) BLK/GRY WIRE BLK/WHT WIRE BLU/RED WIRE BODY CONTROL MODULE (BCM) BRN/YEL WIRE CLOCK- SPRING COMPUTER DATA LINES SYSTEM DC/DC CONVERTER CONTROL MODULE FUSE 12 FUSE 23 FUSE 83 GEAR SHIFT MODULE (GSM) GRN WIRE GRN/ORG WIRE GRN/RED WIRE GRN/VIO WIRE GRY WIRE GRY/BLU WIRE HIGH CURRENT BATTERY JUNCTION BOX (BJB) HOT AT ALL TIMES HOT W/ RUN/START RELAY ENERGIZED LEFT PADDLE SHIFTER (IF EQUIPPED) MEGA FUSE 3 NCA WIRE RED WIRE RIGHT PADDLE SHIFTER (IF EQUIPPED) STEERING COLUMN CONTROL MODULE (SCCM) TRANSMISSION RANGE CONTROL MODULE (TRCM) VBATT W/O AUTO START/ STOP SYSTEM WHT/VIO WIRE YEL/VIO WIRE
