Rear camera circuit, hybrid w/ touch screen display for Ford Mondeo V (2014-2019)
Rear camera circuit, hybrid w/ touch screen display
BATTERY JUNCTION BOX (BJB)
BLK/GRY WIRE
BODY CONTROL MODULE (BCM)
BRN/VIO WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
FUSE 23
HOT IN START OR RUN
HS 1 CAN +
LIN
MICRO -
NCA WIRE
REAR CAMERA VIDEO +
REAR PARKING AID CAMERA
SHIELD
SYNC MODULE (APIM) (UPPER CENTER OF DASH)
VIDEO+
VIO/WHT WIRE
VPWR
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
