Rear camera circuit, hybrid 4.2 inch display for Ford Mondeo V (2014-2019)
Rear camera circuit, hybrid 4.2 inch display
BATTERY JUNCTION BOX (BJB)
BLK/GRY WIRE
BODY CONTROL MODULE (BCM)
BRN/VIO WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
FRONT CONTROL/ DISPLAY INTERFACE MODULE (FCDIM)
FUSE 23
FUSE 32
GRN WIRE
HOT AT ALL TIMES
HOT IN START OR RUN
LIN
MICRO -
NCA WIRE
REAR CAMERA VIDEO +
REAR PARKING AID CAMERA
SHIELD
VBATT
VIDEO+
VIO/RED WIRE
VIO/WHT WIRE
VPWR
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
