Backup lamps circuit, hybrid for Ford Mondeo V (2014-2019)
Backup lamps circuit, hybrid
AUTO DIMMING INTERIOR MIRROR
BATTERY JUNCTION BOX (BJB)
BLK/VIO WIRE
BLU/GRY WIRE
BLU/VIO WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BCM)
BRN/RED WIRE
BRN/VIO WIRE
CAN (+)
COMPUTER DATA LINES SYSTEM
EXTERIOR LAMPS CIRCUIT
FUSE 62
FUSION W/ HIGH SERIES
FUSION W/ LOW SERIES MKZ FUSION
HOT AT ALL TIMES
LEFT REVERSING LAMP
MICRO -
NCA WIRE
PANORAMIC ROOF OPENING PANEL SHIELD MOTOR
PARK
POWERTRAIN CONTROL MODULE (PCM)
PWR
REAR WINDOW BLIND MODULE
REV LPS (FET)
REVERSE
REVERSING LAMP
RIGHT REVERSING LAMP
STOP
TR REF
TR RTN
VIO WIRE
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
YEL WIRE
YEL/GRY WIRE
